63 11 731 Replacing left daytime light LED modules

WARNING: This page does not describe the selected car, but rather 21 other vehicles, including the 2013 BMW 328xi, 2013 BMW 328i, 2012 BMW 328xi, 2012 BMW 328i, and 2011 BMW 328xi. However, it is still accessible from the selected car via links, so may be relevant.

Follow instructions for HANDLING LIGHT BULBS (EXTERIOR LIGHTS) .

Necessary preliminary work:

Remove left headlight

Release screws (1).

Carefully lift LED module (2) slightly upwards.

Fig 1: Identifying LED Module And Screws

Courtesy of BMW OF NORTH AMERICA, INC.

Unfasten plug connection (1) and disconnect.

Remove LED module (2).

Installation note:

Always replace LED modules (2) as a pair.

Replace seal for LED module (2).

Make sure LED module (2) is correctly seated.

Note BULB TYPE .

Fig 2: Identifying LED Module And Connector

Courtesy of BMW OF NORTH AMERICA, INC.
