51 16 340 Removing and installing/replacing lock for right glovebox

WARNING: This page does not describe the selected car, but rather 12 other vehicles, including the 2008 BMW 335xi, 2008 BMW 335i, 2008 BMW 328xi, 2008 BMW 328i, and 2007 BMW 335xi. However, it is still accessible from the selected car via links, so may be relevant.

Open glovebox.

Release screws (1).

Remove lower section (3) and upper section (2) of lock.

Fig 1: Identifying Lock, Lower Section And Upper Section Of Lock

Courtesy of BMW OF NORTH AMERICA, INC.

Replacement:

Insert ignition key (1) in lock cylinder (3).

Turn ignition key (1) slightly, carefully raise catches (2) and pull out lock cylinder (3) with ignition key (1) in direction of arrow.

If necessary, force catches (2) open.

Fig 2: Identifying Catches, Lock Cylinder And Ignition Key

Courtesy of BMW OF NORTH AMERICA, INC.
