65 24 020 Removing and installing or replacing blocking circuit

WARNING: This page does not describe the selected car, but rather 15 other vehicles, including the 2008 BMW 335xi, 2008 BMW 335i, 2008 BMW 328xi, 2008 BMW 328i, and 2008 BMW 323i. However, it is still accessible from the selected car via links, so may be relevant.

Necessary preliminary tasks:

Remove Panel For Roof Pillar At Rear Left .

Unlock plug connections (1) and disconnect.

Release screw (2).

Remove blocking circuit (3) from C-pillar (4).

Fig 1: Identifying Plug Connections, Screw, Blocking Circuit And C-Pillar

Courtesy of BMW OF NORTH AMERICA, INC.

Installation:

Fit blocking circuit (1) so that screw (2) engages thread (3) and locating pin (4) engages bore (5).

Fig 2: Identifying Blocking Circuit, Screw, Thread, Locating Pin And Bore

Courtesy of BMW OF NORTH AMERICA, INC.
