Removal And Installation

WARNING: This page is about a different car, the 2008 Ford RV Cutaway, 2008 Ford Econoline, 2008 Ford E450 Super Duty, and 2008 Ford Cutaway. However, it is still accessible from the selected car via links, so may be relevant.
  1. Remove the evaporator core housing. For additional information, refer to Evaporator Core Housing .
  2. Remove the vacuum reservoir tank.
    1. Remove the screw.
    2. Drill out the heat stake.
    3. Remove the vacuum reservoir tank.
    3. Fig 1: Vacuum Reservoir Tank
    GF0012750Courtesy of FORD MOTOR CO.
  3. Disconnect the vacuum harness.
    4. Fig 2: Vacuum Harness
    GF0012751Courtesy of FORD MOTOR CO.
    NOTE: Use a screw in place of the heat stake to install the vacuum reservoir.
  4. To install, reverse the removal procedure.
