Lower End Components - Exploded View, Flexplate, Flywheel and Crankshaft Rear Seal
WARNING: This page is about a different car, the 2009 Ford Mustang. However, it is still accessible from the selected car via links, so may be relevant.
Fig 1: Exploded View Of Flexplate, Flywheel & Crankshaft Rear Seal With Torque Specifications (1 Of 2)
| Item | Part Number | Description |
|---|---|---|
| 1 | W505255 | Power steering pressure (PSP) tube bracket-to-crossmember bolt |
| 2 | W704980 | Steering column coupling-to-steering gear pinch bolt |
| 3 | 3N725 | Steering column coupling |
| 4 | W710909 | Steering gear bolt (2 required) |
| 5 | 3200 | Steering gear |
| Item | Part Number | Description |
|---|---|---|
| 6 | N808139/ N806168 | Flywheel/flexplate bolt (6 required) |
| 7 | 6375 | Flywheel/flexplate |
| 8 | 6A373 | Engine-to-transmission spacer plate |
| 9 | 6730 | Oil pan drain plug |
| 10 | - | Pin-type retainer (2 required) (part of 12B637) |
| 11 | W701605 | Oil pan bolt (16 required) |
| 12 | 6675 | Oil pan |
| 13 | 6710 | Oil pan gasket |
| 14 | 6310 | Crankshaft oil slinger |
| 15 | 6701 | Crankshaft rear seal |
| 16 | N806155 | Crankshaft rear seal retainer plate bolt (6 required) |
| 17 | 6K318 | Crankshaft rear seal retainer plate |
- For additional information, refer to the procedures.
