Valve Cover - RH: Notes
WARNING: This page is about a different car, the 2009 Ford Pickup, 2009 Ford F550 Super Duty, 2009 Ford F450 Super Duty, and 2009 Ford Cab & Chassis. However, it is still accessible from the selected car via links, so may be relevant.
Material
| Item | Specification |
|---|---|
| Motorcraft Metal Surface Prep ZC-31-A |
- |
| Silicone Gasket and Sealant TA-30 |
WSE-M4G323-A4 |
| Silicone Gasket Remover ZC-30 |
- |
| Item | Description |
|---|---|
| 1 | Transmission wiring harness electrical connector and wiring harness retainer (part of 15525) |
| 2 | Engine wiring harness electrical connector and wiring harness retainer (part of 12B637) |
Fig 2: Exploded View Of Transmission Fluid Fill Tube, Engine Wiring Harness Retainers, RH Valve Cover & Gasket
| Item | Part Number | Description |
|---|---|---|
| 1 | - | Engine wiring harness retainers (part of 12B637) |
| 2 | N859356 | Transmission fluid level indicator tube support bracket bolt |
| 3 | 7A228 | Transmission fluid level indicator tube |
| 4 | - | Engine wiring harness retainers (part of 12B637) |
| 5 | - | Camshaft Position (CMP) sensor electrical connector (part of 12B637) |
| 6 | 6K817 | Crankcase ventilation tube |
| 7 | 6582 | RH valve cover |
| 8 | 6584 | RH valve cover gasket |
