Remove/Install Front Fender Liner - AR88.10-P-1301S

Model 223.0/1/9

Shown on the left side of vehicle

Courtesy of MERCEDES-BENZ USA

	Remove/install
1	Raise vehicle.		AR00.60-P-1006A
2	Remove screws (4).
3	Remove expansion rivets (2).	Number of expansion rivets (2) can vary depending on equipment installed.
		Dismantling tool	Fig 1
4	Remove nuts (3).	Number of nuts (3) can vary depending on equipment installed.
5	Remove fender liner from section (1.1) and fender liner rear section (1.2).
6	Install in the reverse order.

Fig 1: Identifying Dismantling Tool (000 589 95 63 00)
