Remove/Install Multimedia Connection Unit In Rear Passenger Compartment - AR82.60-P-1043S

Model 223

with code 224 (Individual rear seats)

Courtesy of MERCEDES-BENZ USA

Notice	Information on preventing damage to electronic components due to electrostatic discharge		AH54.00-P-0001-01A
	Remove/install
1	Switch off ignition and store transmitter key outside of transmission range (min. 2 m).
2	Open rear stowage compartment.
3	Unclip cover (1) and place to one side with electrical connectors connected.	The number of electrical connectors can vary depending on the equipment variant. Long wedge	Fig 1
4	Unclip ambient lighting (3).	Unclip ambient lighting (3) carefully. Otherwise damage may occur.
5	Disconnect electrical connection (2).
6	Remove HDMI connection (A90/15).
7	Install in the reverse order.

Fig 1: Identifying Long Wedge (115 589 03 59 00)
