RH Variable Camshaft Timing (VCT) Housing and VCT Solenoid

WARNING: This page is about a different car, the 2010 Ford Pickup and 2010 Ford Cab & Chassis. However, it is still accessible from the selected car via links, so may be relevant.
Fig 1: Identifying RH Variable Camshaft Timing Housing And VCT Solenoid
G06126156Courtesy of FORD MOTOR CO.
ITEM DESCRIPTION

Item Part Number Description
1 6M280 Front camshaft bearing cap - RH
2 6C261 Variable Camshaft Timing (VCT) housing - RH
3 6C260 VCT  oil control solenoid assembly - RH
