Check Engine Oil Pressure - AR18.00-P-1250MFG

Engine 139 in model 118, 177, 247

Courtesy of MERCEDES-BENZ USA

	Risk of injury  . Skin or eye injuries may result when handling hot or glowing objects.	Wear protective gloves, protective clothing and safety glasses, if necessary.	AS00.00-Z-0002-01A
	Risk of accident  from vehicle starting off by itself when engine running. Risk of injury  (bruises and burns) resulting from working on the engine while it is being started or when it is running.	Secure vehicle to prevent it from starting off by itself. Wear closed and snug-fitting work clothes. Do not touch hot or rotating parts.	AS00.00-Z-0005-01A
	Risk of injury  to skin and eyes due to handling of engine oil. Risk of poisoning  caused by swallowing engine oil	Wear protective gloves, protective clothing and safety glasses. Do not fill engine oil into beverage containers.	AS18.00-Z-0001-01A
	Check
1	Warm up engine.
2	Check engine oil temperature.
		The engine oil temperature must be at least 100°C.	AD00.00-P-2000-06MFA
3	Check oil level of the engine approx. 5 min after switching off the engine at operating temperature and correct if necessary.	Engine 139 in model 118, 177, 247
		Engine 139 in model 118, 177, 247 Vehicle must be horizontal and standing on its wheels. If the vehicle is not on a level surface, measurements will be incorrect.	AP18.00-P-1812AKI
	Remove
4	Remove bottom engine compartment lining.		AR61.20-P-1105MFR
5	Unscrew drain screw (1) from oil filter housing (2).	Capture escaping engine oil in a suitable container.
6	Connect adapter of the oil pressure tester to the drain screw (1) of the oil filter housing (2).	Oil pressure tester	Fig 1
	Check
7	Start engine and measure oil pressure.	Position oil pressure test equipment such that it is not caught by the poly-V-belt when starting the engine. Otherwise, damage to the oil pressure tester and poly-V-belt can occur. Measure oil pressure at the engine operating temperature. Aid of helper required. In the event of an rpm increase, the oil pressure must increase without delay. Oil pressure at operating temperature 90°C	*BE18.00-P-1001-01K
	Install
8	Disconnect adapter of the oil pressure tester to the drain screw (1) of the oil filter housing (2).	Capture escaping engine oil in a suitable container. Oil pressure tester	Fig 1
9	Tighten drain screw (1) on oil filter housing (2).	Replace sealing ring. Clean area around drain screw (1). Assembly cleaner	*BR00.45-Z-1028-04A
10	Check oil level of the engine approx. 5 min after switching off the engine at operating temperature and correct if necessary.	Engine 139 in model 118, 177, 247
		Engine 139 in model 118, 177 Park vehicle horizontally. If the wheels of the vehicle are not horizontal, measurements will be incorrect.	AP18.00-P-1812AKI
11	Carry out engine test run and check engine for leak tightness.
12	Install lower engine compartment lining.		AR61.20-P-1105MFR

CHECK VALUES FOR OIL PRESSURE

Number	Designation			Engine 139
BE18.00-P-1001-01K	Oil pressure at operating temperature 90°C	-	bar	≥2, 0
		at	1/min	650
		-	bar	≥2, 0
		at	1/min	1000
		-	bar	≥2, 0
		at	1/min	2000
		-	bar	≥2, 3
		at	1/min	4000
		-	bar	≥3, 5
		at	1/min	4500

Fig 1: Identifying Oil Pressure Tester (450 589 13 21 00)

Courtesy of MERCEDES-BENZ USA

REPAIR MATERIALS

Number	Designation	Order number
BR00.45-Z-1028-04A	Assembly cleaner	A 000 986 56 01
