Check Suspension Data, Assign Actual Value To Table - AR40.20-P-0001-01FRB

Model 257 (except 257.361)

with code 489 (AIR BODY CONTROL)

except code 459 (Steel suspension with adjustable damping)

except code 677 (AGILITY CONTROL suspension)

except code M005 (4MATIC)

Courtesy of MERCEDES-BENZ USA

Courtesy of MERCEDES-BENZ USA

Courtesy of MERCEDES-BENZ USA

Courtesy of MERCEDES-BENZ USA
