| AO |
Color code key |
96L |
| A67 |
Inside rearview mirror |
54L |
| B84/16 |
Reversing camera inside rearview mirror display |
40L |
| Code BR9 |
Preinstallation for Telma retarder |
47F |
| Code BR9 |
Preinstallation for Telma retarder |
76C |
| Code CB2 |
Air suspension comfort suspension |
76C |
| Code CB2 |
Air suspension comfort suspension |
30F |
| Code CB2 |
Air suspension comfort suspension |
34F |
| Code E2A |
Tapping of body manufacturer special signals in cockpit |
26F |
| Code E2A |
Tapping of body manufacturer special signals in cockpit |
76A |
| Code E2I |
Auxiliary battery for retrofit consumers, interior compartment |
72F |
| Code E2I |
Auxiliary battery for retrofit consumers, interior compartment |
68F |
| Code E2M |
Auxiliary battery for retrofit consumers, engine compartment |
72F |
| Code E2M |
Auxiliary battery for retrofit consumers, engine compartment |
68F |
| Code E46 |
Socket, in cab |
56E |
| Code E46 |
Socket, in cab |
68E |
| Code EK1 |
Terminal strip for electrical connection |
76D |
| Code EK1 |
Terminal strip for electrical connection |
79D |
| Code ES2 |
Trunk/load compartment 12 V socket |
60F |
| Code ES2 |
Trunk/load compartment 12 V socket |
68E |
| Code EV3 |
Pre-installation of electrical scope for cargo liftgate |
76E |
| Code EV3 |
Pre-installation of electrical scope for cargo liftgate |
79E |
| Code FR3 |
Reversing camera inside rearview mirror display |
38F |
| Code FR3 |
Reversing camera inside rearview mirror display |
52F |
| Code FR3 |
Reversing camera inside rearview mirror display |
76B |
| Code FV1 |
Pre-installation for reversing camera with inside rearview mirror |
38F |
| Code FV1 |
Pre-installation for reversing camera with inside rearview mirror |
43F |
| Code FV1 |
Pre-installation for reversing camera with inside rearview mirror |
52F |
| Code FV1 |
Pre-installation for reversing camera with inside rearview mirror |
76B |
| Code G42 |
7G-TRONIC PLUS |
21F |
| Code G42 |
7G-TRONIC PLUS |
76B |
| Code G42 |
7G-TRONIC PLUS |
76C |
| Code H72 |
Electric roof ventilator II |
76E |
| Code H72 |
Electric roof ventilator II |
79E |
| Code P57 |
Preinstallation for three-way dump truck |
76E |
| Code P57 |
Preinstallation for three-way dump truck |
79E |
| Code T57 |
Right load compartment sliding door electric step |
4E |
| Code T57 |
Right load compartment sliding door electric step |
7E |
| Code T57 |
Right load compartment sliding door electric step |
14F |
| Code T57 |
Right load compartment sliding door electric step |
17E |
| Code T57 |
Right load compartment sliding door electric step |
81A |
| Code T58 |
Left load compartment sliding door electric step |
1E |
| Code T58 |
Left load compartment sliding door electric step |
7F |
| Code T58 |
Left load compartment sliding door electric step |
13E |
| Code T58 |
Left load compartment sliding door electric step |
81A |
| Code T58 |
Left load compartment sliding door electric step |
18F |
| Code V21 |
Luxury interior trim |
76E |
| Code V21 |
Luxury interior trim |
79E |
| F150/4 |
Driver seat base prefuse box |
85L |
| F150/4f1 |
Fuse 1 |
84K |
| F150/5 |
Auxiliary battery prefuse box |
74L |
| F55/5 |
Fuse block 5 (9-pin) |
4A |
| F55/5 |
Fuse block 5 (9-pin) |
12A |
| F55/5 |
Fuse block 5 (9-pin) |
20A |
| F55/5 |
Fuse block 5 (9-pin) |
28A |
| F55/5 |
Fuse block 5 (9-pin) |
36A |
| F55/5 |
Fuse block 5 (9-pin) |
83A |
| F55/5 |
Fuse block 5 (9-pin) |
44A |
| F55/5 |
Fuse block 5 (9-pin) |
52A |
| F55/5 |
Fuse block 5 (9-pin) |
60A |
| F55/5 |
Fuse block 5 (9-pin) |
68A |
| F55/5 |
Fuse block 5 (9-pin) |
75A |
| F55/5f37 |
Fuse 37 |
3B |
| F55/5f38 |
Fuse 38 |
5B |
| F55/5f39 |
Fuse 39 |
15B |
| F55/5f40 |
Fuse 40 |
23B |
| F55/5f41 |
Fuse 41 |
27B |
| F55/5f42 |
Fuse 42 |
40B |
| F55/5f43 |
Fuse 43 |
58B |
| F55/5f44 |
Fuse 44 |
62B |
| F55/5f45 |
Fuse 45 |
65B |
| H13/5 |
Left step warning buzzer |
11L |
| H13/5 |
Left step warning buzzer |
15L |
| H13/6 |
Right step warning buzzer |
19L |
| H13/8 |
Air spring warning buzzer |
36L |
| K100 |
Driver seat base relay holder |
6L |
| K127/1 |
Rear sockets relay |
70L |
| K41/3 |
Circuit 15 relay |
81L |
| N15/11 |
Fully integrated transmission control (VGS) electric controller unit |
23L |
| N26/18 |
Retarder control unit |
49L |
| X11/35x1 |
Air suspension electrical connector 1 |
32L |
| X145/1x6 |
Body manufacturer electrical connector |
28L |
| X169/7x1 |
Reversing camera electrical connector 1 |
44L |
| X58/54 |
Driver seat base 12 V socket |
58L |
| X58/81 |
Left load compartment socket |
62L |
| X58/82 |
Right load compartment socket |
65L |
| Z265z1 |
Terminal 30t connector sleeve |
82G |
| Z50/5 |
Tml. 15 connector sleeve |
77G |
| Z7/106 |
Terminal 30 end sleeve (left step) |
8F |
