(Remove/Install Hydraulic Fluid Reservoir (ABC) - AR32.50-P-0022RK)

MODEL 231

with CODE 487 (Active Body Control (ABC))

Courtesy of MERCEDES-BENZ USA

	Remove/install
	Risk of injury  to skin or eyes from hydraulic fluid spraying out under pressure. Risk of poisoning  from swallowing hydraulic fluid.	Depressurize hydraulic system completely before starting any work on it. Wear protective clothing and safety glasses.	AS00.00-Z-0013-01A
1	Remove the left engine intake air duct
2	Drain hydraulic fluid reservoir (1) using hand pump	Hand pump	Fig 1
3	Remove screw/bolt (3)
4	Detach oil lines (4)	To do so, open clamps (2) using hose clamp pliers. Hose clamp pliers	Fig 2
5	Remove hydraulic fluid reservoir (1)
6	Install in the reverse order
7	Fill and bleed ABC system		AR32.50-P-0021SX

Fig 1: Identifying Hand Pump (210 589 00 71 00)

Courtesy of MERCEDES-BENZ USA

Fig 2: Identifying Hose Clamp Pliers (003 589 03 37 00)

Courtesy of MERCEDES-BENZ USA
