Remove/Install USB Connector In Rear Passenger Compartment - AR82.60-P-1034SA

Model 223

with code 224 (Individual rear seats)

Courtesy of MERCEDES-BENZ USA

Notice	Information on preventing damage to electronic components due to electrostatic discharge		AH54.00-P-0001-01A
	Remove/install
1	Switch off ignition and store transmitter key outside of transmission range (min. 2 m).
2	Open rear stowage compartment.
3	Unclip cover (1) and place to one side with electrical connectors connected.	The number of electrical connectors can vary depending on the equipment variant. Long wedge	Fig 1
4	Unclip ambient lighting (4).	Unclip ambient lighting (4) carefully. Otherwise damage may occur.
5	Disconnect electrical connection (2).
6	Remove USB port (X58/53x1).
7	Disconnect electrical connector (3).
8	Remove USB port (X58/53x2).
9	Install in the reverse order.

Fig 1: Identifying Long Wedge (115 589 03 59 00)
