Remove/Install Dome Lamp In Rear Passenger Compartment - AR82.20-P-0113S

Model 223, 296, 297

Courtesy of MERCEDES-BENZ USA

	Remove/install
1	Unclip rear interior lamp (E15/8, E15/9) with extraction hooks (arrows).	Extraction hook	Fig 1
2	Disconnect electrical connector (1).
3	Remove rear interior lamp (E15/8, E15/9).
4	Install in the reverse order.

Fig 1: Identifying Extraction Hook (140 589 02 33 00)

Courtesy of MERCEDES-BENZ USA
