Remove/Install Sealing Rail On Outside - AR72.10-S-1700E

Model 447

Except Code VQ1 (AVANTGARDE)

Model 448.7

Courtesy of MERCEDES-BENZ USA

	Remove/install
1	Remove sealing rail (1) starting at rear	Observe installation position of sealing rail (1) Long wedge	Fig 1
2	Install in the reverse order

Fig 1: Identifying Long Wedge (115 589 03 59 00)

Courtesy of MERCEDES-BENZ USA
