Check Suspension Data, Assign Actual Value To Table - AR40.20-P-0001-01MEE
Model 167.1 (except 167.161/188/189)
with code 489 (AMG RIDE CONTROL+)
except code 460 (Canada version)
except code 490 (Electrohydraulic suspension)
except code 491 (Lowered suspension with steel springs)
except code 9U4 (Control code, wheel diameter, standard (size 750/760))
except code ME05 (Hybrid drive 85 kW-94 kW variant (incl. plug-in))
Model 167.3 (except 167.361/388/389)
with code 489 (AMG RIDE CONTROL+)
except code 490 (Electrohydraulic suspension)
except code ME05 (Hybrid drive 85 kW-94 kW variant (incl. plug-in))
Model 167.9 (except 167.989)
with code 489 (AMG RIDE CONTROL+)
except code 490 (Electrohydraulic suspension)
except code ME05 (Hybrid drive 85 kW-94 kW variant (incl. plug-in))
