Remove/Install Rear Cover On Center Console - AR68.20-P-2358FRX

Model 290 with code 224 (Individual rear seats)

Courtesy of MERCEDES-BENZ USA

	Remove/install
1	Unclip cover (1) and remove (arrows).	Long wedge	Fig 1
2	Remove air vents (2) from cover (1).	Only when replacing cover (1).
3	Install in the reverse order

Fig 1: Identifying Long Wedge (115 589 03 59 00)

Courtesy of MERCEDES-BENZ USA
