Check Suspension Data, Assign Actual Value To Table - AR40.20-P-0001-01MBN

Model 247.7 (except247.751/753/754)

with code 485 (Comfort suspension)

with code 494 (US version)

with code U55 (Mutti-link axle)

except code 457 (Comfort suspension with adjustable damping)

except code U54 (Compound-link axle)

Courtesy of MERCEDES-BENZ USA

Courtesy of MERCEDES-BENZ USA

Courtesy of MERCEDES-BENZ USA

Courtesy of MERCEDES-BENZ USA
