Brake System - Inspect Fluid Level - AP42.10-P-4210GA

Model 463

as of model year 2019

Shown in model 463.349

Courtesy of MERCEDES-BENZ USA

	Risk of poisoning  from swallowing brake fluid. Risk of injury  from skin and eye contact with brake fluid	Only pour brake fluid into suitable and appropriately marked containers. Wear protective clothing and eye protection when handling brake fluid.	AS42.50-Z-0001-01A
	Notes on repairs to brake system		AH42.00-P-0003-01A
	Brake fluid notes		AH42.50-P-0001-01A
	Check
1	Check fluid level in brake fluid reservoir (1).
	General brake fluid		BB00.40-P-0330-01A
	Brake fluids (DOT 4 plus)		BB00.40-P-0331-00A
		The fluid level must be between the max. and min. marks on the brake fluid reservoir (1) If the fluid level is too low, ↓ rectify problem. After obtaining special order. If the fluid level is too high, ↓ extract brake fluid up to max. mark.
