Windshield Wiper System, Function - GF82.30-P-0001GW
Model 463
as of model year 2013
Model 463 as of 03.04.2018 except model 463.342
Model 463 up to 02.04.2018 or model 463.342
Windshield wiper system, general
The windshield wiper system controls the wiping and washing of the windshield and the rear window (except model 463.202).
The windshield wiper system comprises the following subfunctions, which are described in separate documents:
- Windshield wiper, function
- Windshield washer, function
- Headlamp cleaning system, function
- Spray nozzle and spray nozzle hose heater, function
- Rear window windshield wiper system function (except model 463.202)
| Windshield wiper, function | GF82.30-P-3004GW | ||
| Windshield washer, function | GF82.35-P-3002GW | ||
| Headlamp cleaning system, function | GF82.15-P-3000GW | ||
| Spray nozzle and spray nozzle hose heater, function | GF82.35-P-3007GW | ||
| Rear window wiper system, function | Model 463 (except 463.202) as of model year 2013 |
GF82.30-P-2400GW |
