Wiring Diagram Of Ground Cabling - PE00.19-P-2800-97FBH
Model 205 up to model year 2019 W15/7 Model 253 (except 253.99) up to model year 2020 W15/7
| Code: | Designation: | Position: |
|---|---|---|
| A0 | Use of wiring diagrams | 96L |
| A2/11 | Video system | 73L |
| A48/1 | Special signal system operating unit | 77L |
| A98 | Panoramic sliding roof control module | 22A |
| A98/1 | Sliding roof control module | 18A |
| B11/15 | Radiator sensor for engine diagnosis | 8L |
| B37 | Accelerator pedal sensor | 68L |
| B38/2 | Rain/light sensor with additional functions | 59L |
| B44/2 | Right front door interior protection sensor | 17L |
| B44/4 | Right rear interior protection sensor | 21L |
| Code 401 | Seat climate control for driver and front passenger | 33F |
| Code 401 | Seat climate control for driver and front passenger | 37G |
| Code 460 | Canada version | 42G |
| Code 466 | Active engine mount | 46F |
| Code 466 | Active engine mount | 50F |
| Code 474 | Diesel particulate filter | 41F |
| Code 494 | USA version | 42G |
| Code 494 | USA version | 6F |
| Code 551 | Anti-theft alarm system (ATA [EDW]) | 11F |
| Code 830 | Additional parts for China vehicles | 87F |
| Code 873 | Seat heater for driver and front passenger | 33F |
| Code 873 | Seat heater for driver and front passenger | 37G |
| Code 882 | Interior protection and tow-away protection | 11F |
| Code 917 | PZEV emission USA | 6F |
| Code 962 | Hella roof attachment | 84G |
| Code 970 | Police emergency vehicles | 70F |
| Code 974 | Fire department lead emergency vehicle preinstallation | 70F |
| Code 975 | Emergency physician vehicle preinstallation | 70F |
| Code B53 | Acoustic ambient protection | 28F |
| Code B63 | AMG eSound | 5A |
| Code F205 | MODEL SERIES 205 | 11F |
| Code F205 | MODEL SERIES 205 | 11A |
| Code F205 | MODEL SERIES 205 | 5B |
| Code F253 | MODEL SERIES 253 | 5B |
| Code F253 | MODEL SERIES 253 | 50F |
| Code F253 | MODEL SERIES 253 | 91F |
| Code FA | CABRIOLET | 11C |
| Code FA | CABRIOLET | 14C |
| Code L | LEFT-HAND DRIVE | 37F |
| Code L | LEFT-HAND DRIVE | 6B |
| Code L | LEFT-HAND DRIVE | 46F |
| Code M177 | SPARK-IGNITION ENGINE M177 | 50F |
| Code M177 | SPARK-IGNITION ENGINE M177 | 91F |
| Code M276 | SPARK-IGNITION ENGINE M276 | 91F |
| Code M651 | DIESEL ENGINE 0M651 | 41F |
| Code ME04 | Hybrid drive 20 KW VARIANT | 62F |
| Code ME05 | HYBRID DRIVE 80 KW VARIANT (INCLUDING PLUGIN) | 62F |
| Code ME06 | Hybrid drive 50 KW VARIANT (INCLUDING PLUGIN) | 66F |
| Code ME06 | Hybrid drive 50 KW VARIANT (INCLUDING PLUGIN) | 62F |
| Code R | RIGHT-HAND DRIVE | 6B |
| Code R | RIGHT-HAND DRIVE | 1A |
| Code R | RIGHT-HAND DRIVE | 23F |
| H3/1 | Alarm siren | 13L |
| H4/16 | Sound generator | 31L |
| K114 | ECO start/stop function additional battery relay | 64L |
| N10/6 | Front SAM control unit | 26L |
| N112/1 | Telematics services communication module | 88L |
| N112/1x1 | Telematics services communication module electrical connector | 88J |
| N127 | Drivetrain control unit | 3A |
| N25/17 | Front seat heater control unit | 39L |
| N25/4 | Front passenger seat heater control unit | 35L |
| N3/42 | Active engine mounts control unit | 52L |
| N3/42 | Active engine mounts control unit | 48L |
| N40/1 | Engine sound control unit | 9A |
| N45 | All-wheel drive control unit | 93L |
| N70 | Overhead control panel control unit | 14A |
| N74 | Soot particulate sensor control unit | 43L |
| U362 | Valid for gasoline engine 274 | 7K |
| W15/7 | Right front footwell ground point | 26A |
| X1/47 | Two-way radio main switch connecting point | 83L |
| X101/4 | Right rear frame floor assembly/underfloor electrical connector | 44H |
| X11/4 | Diagnostic connector | 56L |
| X18/15 | German Association of the Automotive Industry connecting point | 85L |
| X18/35 | Cockpit wiring harness and frame floor assembly electrical connector | 55H |
| X187 | Engine run-on feature connecting point | 82L |
| X262/1 | Active engine mount electrical connector | 51H |
| X28/30 | Frame floor assembly/front passenger seat electrical connector | 34H |
| X35/2 | Front passenger door electrical connector | 16H |
| X55/16 | Front passenger seat electrical connector | 38H |
| X58/7 | Socket (2-pin, 12V) | 80L |
| Z6/30 | Circuit 31 connector sleeve | 8G |
| Z6/30 | Circuit 31 connector sleeve | 30H |
| Z6/30 | Circuit 31 connector sleeve | 42G |
| Z6/30 | Circuit 31 connector sleeve | 72H |
