Wiring Diagram Of Soldered Points/Z Connector Sleeves - PE00.19-P-2600-97FBA
Model 205 up to model year 2019 Z6/117z1, Z6/118z1, Z141/1z1, Z232/17z1
Model 253 (except 253.99) up to model year 2020 Z6/117z1, Z6/118z1, Z141/1z1, Z232/17z1
| Code: | Designation: | Position: |
|---|---|---|
| A0 | Use of wiring diagrams | 88L |
| Code 2U1 | Radiator shutters | 26G |
| Code 301 | Smoker's package | 61D |
| Code 301 | Smoker's package | 64D |
| Code 5U3 | AIRPANEL | 25A |
| Code 875 | Heated windshield washer system | 48A |
| Code 876 | Interior lights package | 68D |
| Code F253 | Model Series 253 | 6F |
| Code M177 | Spark-Ignition Engine M177 | 6F |
| Code M177 | Spark-Ignition Engine M177 | 41G |
| Code M274 | Spark-Ignition Engine M274 | 45H |
| Code M276 | Spark-Ignition Engine M276 | 45H |
| Code M626 | Diesel Engine OM626 | 45G |
| Code M651 | Diesel Engine OM651 | 19G |
| Code M651 | Diesel Engine OM651 | 45G |
| Code ME04 | Hybrid drive 20 KW Variant | 14A |
| Code ME04 | Hybrid drive 20 KW Variant | 43A |
| Code ME05 | Hybrid Drive 80 KW Variant (Including Plug-in) | 37G |
| Code ME05 | Hybrid Drive 80 KW Variant (Including Plug-in) | 43A |
| Code ME06 | Hybrid drive 50 KW Variant (Including Plug-in) | 37G |
| Code ME06 | Hybrid drive 50 KW Variant (Including Plug-in) | 1F |
| Code ME06 | Hybrid drive 50 KW Variant (Including Plug-in) | 14A |
| Code ME06 | Hybrid drive 50 KW Variant (Including Plug-in) | 43B |
| Code U63 | Driving school package | 68E |
| E1 | Left front lamp unit | 58A |
| E20/18 | Front center console cup holder ambiance illumination | 72L |
| H2 | Left fanfare horn | 58L |
| H2/1 | Right fanfare horn | 33L |
| K40/8 | Engine fuse and relay module | 14L |
| K40/8 | Engine fuse and relay module | 52L |
| K40/8f120 | Fuse 120 | 13L |
| K40/8kJ | CPC relay | 18L |
| M2/37 | Radiator trim flap actuator motor | 31A |
| M4/7 | Fan motor | 24L |
| M43/6 | Low temperature circuit circulation pump 1 | 8L |
| M43/6 | Low temperature circuit circulation pump 1 | 47L |
| M43/7 | Low temperature circuit circulation pump 2 | 43L |
| M43/7 | Low temperature circuit circulation pump 2 | 39L |
| M45 | Coolant circulation pump | 46A |
| M87 | Radiator shutters actuator motor | 29L |
| N10/6 | Front SAM control unit | 80L |
| N127 | Drivetrain control unit | 23A |
| R2/11 | Spray nozzle hose heater | 51A |
| R3 | Front cigarette lighter with ashtray illumination | 66L |
| R3 | Front cigarette lighter with ashtray illumination | 76L |
| U165 | Valid for AMG | 11J |
| U165 | Valid for AMG | 12G |
| U561 | Valid for Delphi system | 19G |
| W2 | Right front ground point (at lamp unit) | 36L |
| W9 | Left front ground point (at lamp unit) | 54L |
| W9 | Left front ground point (at lamp unit) | 56L |
| X138/1 | Front center console electrical connector | 72G |
| X25/7 | Engine compartment/frame floor assembly electrical connector | 4H |
| X25/7 | Engine compartment/frame floor assembly electrical connector | 16D |
| X25/7 | Engine compartment/frame floor assembly electrical connector | 21D |
| X58/1 | Vehicle interior power outlet | 62L |
| X58/18 | Right rear center console 12V socket | 70L |
| Y19/3 | Front evaporator shutoff valve | 3L |
| Y73/2 | Low-temperature circuit switchover valve 2 | 18A |
| Z141/1z1 | Circuit 87 C1 connector sleeve | 5A |
| Z232/17z1 | Center console ambiance illumination connector sleeve (yellow) | 70A |
| Z6/117z1 | Left front ground point connector sleeve (on lamp unit) | 54F |
| Z6/118z1 | Right front ground line connector sleeve (in wiring harness) | 36F |
