| A9/10 |
Refrigerant compressor with magnetic clutch |
16E |
| A9/10 |
Refrigerant compressor with magnetic clutch |
43E |
| B109 |
Clutch travel sensor |
27D |
| B11/17 |
Coolant temperature sensor |
5K |
| B11/17 |
Coolant temperature sensor |
34K |
| B17/13 |
Charge air temperature sensor |
7D |
| B17/13 |
Charge air temperature sensor |
35D |
| B4/16 |
Rail pressure sensor |
4K |
| B4/16 |
Rail pressure sensor |
33K |
| B5/6 |
Boost pressure sensor |
8D |
| B5/6 |
Boost pressure sensor |
37D |
| B6/23 |
Rpm sensor |
7K |
| B6/23 |
Rpm sensor |
35K |
| CAN B |
Interior CAN |
18C |
| CAN B |
Interior CAN |
46C |
| CAN C |
Drive train CAN |
11G |
| CAN C |
Drive train CAN |
14J |
| CAN C |
Drive train CAN |
16G |
| CAN C |
Drive train CAN |
39G |
| CAN C |
Drive train CAN |
42J |
| CAN C |
Drive train CAN |
44G |
| CAN C1 |
Engine CAN |
14G |
| CAN C1 |
Engine CAN |
42G |
| Code G42 |
7G-TR0NIC PLUS |
16J |
| Code GD8 |
ECO Gear 360 6-speed manual transmission |
26F |
| Code GD8 |
ECO Gear 360 6-speed manual transmission |
26C |
| Code GD9 |
6-speed manual transmission ECO Gear 480 |
26F |
| Code GD9 |
6-speed manual transmission ECO Gear 480 |
26C |
| Code GE2 |
6-speed manual transmission ZF EL 55 |
26J |
| Code GE2 |
6-speed manual transmission ZF EL 55 |
26F |
| Code GK8 |
Automatic transmission 9G-TRONIC |
44H |
| Code HH4 |
THERMOTRONIC automatic air conditioning |
10B |
| Code HH4 |
THERMOTRONIC automatic air conditioning |
38B |
| Code HH9 |
Semi-automatic air conditioning, TEMPMATIC |
38B |
| Code HH9 |
Semi-automatic air conditioning, TEMPMATIC |
10D |
| Code MG3 |
Engine 0M 651 DE 22 LA 120 kW (163 hp) 3800 RPM |
5F |
| Code MH8 |
SULEV low-emission engine |
5E |
| Code MH8 |
SULEV low-emission engine |
34F |
| Code MI1 |
Engine 0M 651 DE 22 LA 84 kW (114 hp) 3800 RPM |
5F |
| Code MI1 |
Engine 0M 651 DE 22 LA 84 kW (114 hp) 3800 RPM |
34F |
| Code MI2 |
Engine 0M 651 DE 22 LA 105 kW (143 hp) 3800 RPM |
5F |
| Code MI2 |
Engine 0M 651 DE 22 LA 105 kW (143 hp) 3800 RPM |
34F |
| Code MJ8 |
ECO start/stop function |
27G |
| Code MJ8 |
ECO start/stop function |
27D |
| Code MR4 |
Engine 0M 651 DE 22 LA 110 kW (150 hp) 3800 RPM |
5G |
| Code ZL3 |
National version for Latin America |
26H |
| Code ZL3 |
National version for Latin America |
27C |
| Code ZL3 |
National version for Latin America |
27F |
| Code ZL3 |
National version for Latin America |
10A |
| Code ZL3 |
National version for Latin America |
16H |
| F152kD |
Tml. 87M relay |
5D |
| F152kD |
Tml. 87M relay |
33D |
| Flex E |
Chassis FlexRay |
21E |
| Flex E |
Chassis FlexRay |
22D |
| Flex E |
Chassis FlexRay |
49E |
| Flex E |
Chassis FlexRay |
50D |
| L5/11 |
Crankshaft position sensor |
8K |
| L5/11 |
Crankshaft position sensor |
36K |
| LIN B8 |
Climate control LIN |
14C |
| LIN B8 |
Climate control LIN |
41C |
| N10 |
SAM control unit |
16B |
| N10 |
SAM control unit |
44B |
| N127 |
Drivetrain control unit |
21F |
| N127 |
Drivetrain control unit |
49F |
| N15/11 |
Fully integrated transmission control (VGS) electric controller unit |
17J |
| N15/3 |
Electronic transmission control (EGS) control unit |
46J |
| N22/2 |
Automatic air conditioning control and operating unit |
11B |
| N22/2 |
Automatic air conditioning control and operating unit |
39B |
| N22/2 |
Automatic air conditioning control and operating unit |
11D |
| N3/31 |
CDI control unit |
6G |
| N3/31 |
CDI control unit |
35G |
| N30/4 |
ESP® control unit |
25B |
| N30/4 |
ESP® control unit |
54B |
| N73/8 |
Electronic ignition lock (EZS) control unit |
21B |
| N73/8 |
Electronic ignition lock (EZS) control unit |
49B |
| S40/6 |
Clutch pedal switch |
28H |
| S40/6 |
Clutch pedal switch |
28K |
| S40/7 |
Upper clutch pedal switch |
28H |
| S40/7 |
Upper clutch pedal switch |
28K |
| Y74/5 |
Pressure regulator valve |
6D |
| Y74/5 |
Pressure regulator valve |
34D |
| Y76/1 |
Cylinder 1 fuel injector |
3F |
| Y76/1 |
Cylinder 1 fuel injector |
31F |
| Y76/2 |
Cylinder 2 fuel injector |
3G |
| Y76/2 |
Cylinder 2 fuel injector |
31G |
| Y76/3 |
Cylinder 3 fuel injector |
3G |
| Y76/3 |
Cylinder 3 fuel injector |
31G |
| Y76/4 |
Cylinder 4 fuel injector |
3G |
| Y76/4 |
Cylinder 4 fuel injector |
31G |
| Y94/3 |
Quantity control valve |
9K |
| Y94/3 |
Quantity control valve |
38K |
