| A1 |
Instrument cluster |
28C |
| A1 |
Instrument cluster |
58C |
| A1e17 |
ABS warning lamp |
27B |
| A1e17 |
ABS warning lamp |
56B |
| A1e23 |
"Brake system malfunction" warning lamp |
28B |
| A1e23 |
"Brake system malfunction" warning lamp |
57B |
| A1e41 |
ESP® warning lamp |
29B |
| A1e41 |
ESP® warning lamp |
59B |
| A1p13 |
Multifunction display |
30C |
| A1p13 |
Multifunction display |
60C |
| A2/153 |
Roof antenna |
13D |
| A2/153 |
Roof antenna |
43D |
| A2/161 |
WLAN antenna 1 |
13D |
| A2/161 |
WLAN antenna 1 |
43D |
| A2/162 |
Wi-fi antenna 2 |
13E |
| A2/162 |
Wi-fi antenna 2 |
43E |
| A2/170 |
Bluetooth® and WLAN antenna |
13E |
| A2/170 |
Bluetooth® and WLAN antenna |
43E |
| A2/171 |
Sate llite Digital Audio Radio Service (SDARS) antenna |
13E |
| A2/171 |
Sate llite Digital Audio Radio Service (SDARS) antenna |
43E |
| A2/191 |
Antenna switchbox |
13F |
| A2/191 |
Antenna switchbox |
43F |
| A26/17 |
Head unit |
22C |
| A26/17 |
Head unit |
22F |
| A26/17 |
Head unit |
51C |
| A26/17 |
Head unit |
51F |
| A40/8 |
Audio/COMAND display control unit |
15F |
| A40/8 |
Audio/COMAND display control unit |
45F |
| A90/5 |
Multimedia connection unit |
14D |
| A90/5 |
Multimedia connection unit |
44D |
| B25/12 |
Hands-free system microphone |
14D |
| B25/12 |
Hands-free system microphone |
44D |
| CAN A |
Telematics CAN |
18G |
| CAN A |
Telematics CAN |
18J |
| CAN A |
Telematics CAN |
47G |
| CAN A |
Telematics CAN |
47J |
| CAN MMI |
User interface CAN |
7C |
| CAN MMI |
User interface CAN |
13C |
| CAN HMI |
User interface CAN |
22C |
| CAN HMI |
User interface CAN |
25D |
| CAN HMI |
User interface CAN |
25H |
| CAN HMI |
User interface CAN |
36C |
| CAN HMI |
User interface CAN |
43C |
| CAN HMI |
User interface CAN |
52C |
| CAN HMI |
User interface CAN |
55D |
| CAN HMI |
User interface CAN |
55H |
| CAN LR |
Steering wheel CAN |
9J |
| CAN LR |
Steering wheel CAN |
39J |
| Code E1A |
MBCONNECT-5 |
20C |
| Code E1A |
MBCONNECT-5 |
50C |
| Code E1A |
MBCONNECT-5 |
43H |
| Code E1A |
MBCONNECT-5 |
14H |
| Code E1C |
Audio 25 |
20E |
| Code E1C |
Audio 25 |
50E |
| Code E1C |
Audio 25 |
43H |
| Code E1C |
Audio 25 |
14H |
| Code E10 |
Entry-1 evel radio |
27H |
| Code E10 |
Entry-1 evel radio |
57H |
| Code EJ2 |
Audio 20 |
20E |
| Code EJ2 |
Audio 20 |
50E |
| Code EJ2 |
Audio 20 |
43J |
| Code EJ2 |
Audio 20 |
14J |
| Code EJ9 |
COMAND Online |
20F |
| Code EJ9 |
COMAND Online |
50F |
| Code EJ9 |
COMAND Online |
43J |
| Code EJ9 |
COMAND Online |
14J |
| Flex E |
Chassis FlexRay |
3F |
| Flex E |
Chassis FlexRay |
33F |
| H23/1 |
Left front tweeter |
14E |
| H23/1 |
Left front tweeter |
44E |
| H23/11 |
Left rear tweeter |
14E |
| H23/11 |
Left rear tweeter |
44E |
| H23/12 |
Right rear tweeter |
14E |
| H23/12 |
Right rear tweeter |
44E |
| H23/13 |
Additional left rear tweeter |
14F |
| H23/13 |
Additional left rear tweeter |
44F |
| H23/14 |
Additional right rear tweeter |
15D |
| H23/14 |
Additional right rear tweeter |
45D |
| H23/15 |
Left rear woofer/mid-range speaker |
15D |
| H23/15 |
Left rear woofer/mid-range speaker |
45D |
| H23/16 |
Right rear woofer/mid-range speaker |
15E |
| H23/16 |
Right rear woofer/mid-range speaker |
45E |
| H23/17 |
Additional left rear woofer/mid-range speaker |
15E |
| H23/17 |
Additional left rear woofer/mid-range speaker |
45E |
| H23/18 |
Additional right rear woofer/mid-range speaker |
15E |
| H23/18 |
Additional right rear woofer/mid-range speaker |
45E |
| H23/2 |
Right front tweeter |
15F |
| H23/2 |
Right front tweeter |
45F |
| H23/22 |
Center front mid-range speaker |
17D |
| H23/22 |
Center front mid-range speaker |
46D |
| H23/51 |
Left sliding door tweeter |
17D |
| H23/51 |
Left sliding door tweeter |
46D |
| H23/52 |
Right sliding door tweeter |
17E |
| H23/52 |
Right sliding door tweeter |
46E |
| H23/55 |
Left sliding door woofer/mid-range speaker |
17E |
| H23/55 |
Left sliding door woofer/mid-range speaker |
46E |
| H23/56 |
Right sliding door woofer/mid-range speaker |
17E |
| H23/56 |
Right sliding door woofer/mid-range speaker |
46E |
| H23/61 |
Left side wall trim tweeter |
12D |
| H23/62 |
Right side wall trim tweeter |
12E |
| H23/65 |
Left side wall trim woofer/mid-range speaker |
12E |
| H23/66 |
Right side wall trim woofer/mid-range speaker |
12E |
| H23/7 |
Left front door woofer/midrange speaker |
17F |
| H23/7 |
Left front door woofer/midrange speaker |
46F |
| H23/8 |
Right front door woofer/midrange speaker |
12D |
| N135 |
Steering wheel electronics |
11K |
| N135 |
Steering wheel electronics |
40K |
| N72/11 |
Head unit control panel control unit |
45J |
| N72/11 |
Head unit control panel control unit |
15J |
| N73/8 |
Electronic ignition lock (EZS) control unit |
3B |
| N73/8 |
Electronic ignition lock (EZS) control unit |
33B |
| N80 |
Steering column tube module (MRM) control unit |
7H |
| N80 |
Steering column tube module (MRM) control unit |
36H |
| N87/12 |
Radio |
28H |
| N87/12 |
Radio |
58H |
| S163/1 |
Instrument cluster multifunction steering wheel button group |
13H |
| S163/1 |
Instrument cluster multifunction steering wheel button group |
42H |
| S163/2 |
Head unit multifunction steering wheel button group |
12J |
| S163/2 |
Head unit multifunction steering wheel button group |
42J |
