Sketch Sheet For Paint Coat Thickness Form - Of98.00-P-3000-03AH

WARNING: This page does not describe the selected car, but rather 12 other vehicles, including the 2023 Mercedes-Benz CLA45 AMG, 2023 Mercedes-Benz CLA35 AMG, 2023 Mercedes-Benz CLA250, 2022 Mercedes-Benz CLA45 AMG, and 2022 Mercedes-Benz CLA35 AMG. However, it is still accessible from the selected car via links, so may be relevant.

Model 118.3

G15880251Courtesy of MERCEDES-BENZ USA

IMPORTANT

Layer thickness specification in μm (mean value from 3 measurements in each case)

G16064154Courtesy of MERCEDES-BENZ USA
