Retrofit Front Spoiler On Front Bumper - AZ88.20-P-0018MFC
WARNING: This page does not describe the selected car, but rather 12 other vehicles, including the 2023 Mercedes-Benz CLA45 AMG, 2023 Mercedes-Benz CLA35 AMG, 2023 Mercedes-Benz CLA250, 2022 Mercedes-Benz CLA45 AMG, and 2022 Mercedes-Benz CLA35 AMG. However, it is still accessible from the selected car via links, so may be relevant.
Model 118.3 up to 6/1/23
except code 772 (AMG styling - Front spoiler, side skirts)
except code 830 (China version)
| Install | |||
| 1 | Lift vehicle with lifting platform. | ||
| AR00.60-P-1006A | |||
| 2 | Attach the front spoiler (1). | When pressing on, ensure that the pressure is applied directly on the adhesive strips. The maximum adhesive strength is reached only after approx. 72 h at 20°C. Avoid any contact with moisture (e.g. rain, fog, frost, washing facility) or any mechanical stress within the first 24 h. Otherwise, adhesion problems may occur. |
AZ88.20-P-0018-01MFC |
| Cleaner | *BR00.45-Z-1025-04A | ||
| 3 | Lower vehicle with vehicle lift. | ||
| AR00.60-P-1006A | |||
| Update vehicle documentation (VeDoc) | |||
| 4 | Attach note "Front spoiler retrofitted in accordance with AZ88.20-P-0018MFC" under field organization texts to design group 88. |
REPAIR MATERIALS
| Number | Designation | Order number |
|---|---|---|
| BR00.45-Z-1025-04A | Cleaner | A 005 989 19 71 |
PARTS ORDERING NOTE
| Part no. | Designation | Quantity |
|---|---|---|
| KG 98 (see XENTRY Portal Parts information) | Parts kit Front spoiler | 1 |
