Carry Out Delivery Control For New Vehicles - AP00.20-P-1101A

Model 117, 118, 156, 166, 167, 172, 176, 177, 205, 206, 213, 217, 222, 223, 231, 238, 243, 247, 253, 257, 290, 292, 293, 461, 463

Courtesy of MERCEDES-BENZ USA

		Input condition not OK:	ⓧ
Completed
[X]
↓			↓
	Vehicle Exterior, Body
□	Check windows, paintwork, chrome and plastic parts for transport damage.	...............	◦
□	Check the condition of the underside of the vehicle in the front and rear area for transport damage.		◦
□	Check the condition of the underside of the vehicle in the area of the high-voltage battery and the front and rear underbody panels for damage.	...............	◦
		Model 293 If necessary, use commercially available devices/tools.  Swiveling underbody inspection mirror with illumination. If problems are determined,, ↓ Place vehicle on vehicle lift and check problems again. After obtaining special order.
	Tires, Wheels
□	Check the tires and rims for transport damage.	...............	◦
	Vehicle interior
□	Check vehicle interior for damage and condition.	...............	◦
□	Check charge level of high-voltage battery.	...............	◦
		Vehicle with high-voltage battery. Model 118.386/686, 177.086/186, 247.086/786 Model 166.063, 167.117/317, 205.013/047/053/054/147/213/247/2 53, 213.011/016/050/053/054/153/155/2 11/216/253, 222.163/173, 253.311/353/354/911/953/954 Model 167.154/354 except code 830 (China version) Model 167.154/354 with code 830 (China version) Model 205.012/212 Model 222.004/057/104/157 Model 243 Model 253.99, 293 Model 290.679
□	Check navigation system for completeness.	...............	◦	SI54.10-P-0024A
□	Miscellaneous
□	Enter any other faults into table.	...............
