Bolt Plan For Timing Case Cover - AR01.40-P-8000-01CD

ENGINE 651 in MODEL 166, 172, 204, 205, 207, 212, 218, 221, 222, 253

IMPORTANT Pay attention to different screw/bolt lengths and screw/bolt diameters.

G12078850
