Remove/Install Seal Of Glass Roof On Rear Panoramic Roof - AR77.21-P-0620EW

MODEL 166, 212.0/1 with CODE (413) Panoramic glass roof with top sliding roof

Shows model 212.1

	Removing
1.1	Remove front glass roof	Model 166	AR77.21-P-0500GQ
1.2	Remove left and right drip rail on panoramic roof	Model 212.0, 212.1	AR88.80-P-4000EW
2	Move front glass roof to tilt position	Model 212.0, 212.1
3	Pull seal (2) out of groove on rear glass roof (1)
	Install
4	Clean and lubricate seal (2) on rear glass roof (1)	Antifriction agent	*BR00.45-Z-1010-06A
5	Align seal (2) with rear glass roof (1) and insert in groove of rear glass roof (1)	Model 166: For this purpose press seal (2) into rear glass roof (1) at side with long wedge.	Fig 1
6	Close front glass roof	Model 212.0, 212.1
7.1	Install left and right drip rail on panoramic roof	Model 212.0, 212.1	AR88.80-P-4000EW
7.2	Install front glass roof	Model 166	AR77.21-P-0500GQ

Fig 1: Identifying Long Wedge (115 589 03 59 00)
