| A0 |
Color code key |
32L |
| CAN B |
Interior CAN |
7K |
| F34 |
Interior fuse box |
3L |
| F34f126 |
Fuse 126 |
1K |
| M28/1 |
Front passenger seat fore/aft adjustment motor |
18L |
| M28/2 |
Front passenger seat height adjustment motor |
16L |
| M28/3 |
Front passenger seat inclination adjustment motor |
14L |
| M28/4 |
Front passenger seat head restraint adjustment motor |
12L |
| M28/5 |
Front passenger seat backrest inclination adjustment motor |
10L |
| N32/2 |
Front passenger seat control unit |
4A |
| N32/2 |
Front passenger seat control unit |
11A |
| N32/2 |
Front passenger seat control unit |
20A |
| N32/2 |
Front passenger seat control unit |
28A |
| N32/24 |
Front passenger seat lumbar support adjustment control unit |
25L |
| S159/3 |
Left EASY-ENTRY system limit switch |
21L |
| S159/4 |
Right EASY-ENTRY system limit switch |
21L |
| S159/4x1 |
Right EASY-ENTRY system limit switch electrical connector |
21H |
| U12 |
Valid for left-hand drive vehicles |
5C |
| U12 |
Valid for left-hand drive vehicles |
20C |
| U13 |
Valid for right-hand drive vehicles |
5C |
| U13 |
Valid for right-hand drive vehicles |
20D |
| U71 |
Valid for fully electric seat adjustment with memory function |
23C |
| U998 |
Valid for EASY-ENTRY |
20C |
| W19 |
Right front seat crossmember ground point |
3E |
| X30/32 |
Left vehicle floor interior CAN voltage distributor electrical connector |
6L |
| X30/33 |
Right vehicle floor interior CAN voltage distributor electrical connector |
7L |
