Electrical function schematic for multicontour seat - PE91.25-P-2051-97EAA

Code:	Designation:	Position:
1	Circuit 15, status	4G
2	Power supply, status ON	4D
CAN B	Interior CAN	3G
M40	Multicontour seat pneumatic pump	3C
N10/2	Rear SAM control unit with fuse and relay module	3E
N73	Electronic ignition switch control unit	3J

Fig 1: Multicontour Seat Electrical Function Schematic

Courtesy of MERCEDES-BENZ USA
