| A0 |
Color code key |
48L |
| A2/53 |
Mobile phone and stationary heater radio remote control antenna splitter |
20L |
| A28/11 |
Multifunction antenna |
16L |
| A28/11 |
Multifunction antenna |
17L |
| A28/13 |
Compensator/cellular telephone system UMTS |
24L |
| A40/3 |
COMAND control unit |
34L |
| A6 |
Stationary heater unit |
4A |
| A6 |
Stationary heater unit |
12A |
| A6 |
Stationary heater unit |
20A |
| A6 |
Stationary heater unit |
28A |
| A6 |
Stationary heater unit |
37A |
| A6/1 |
Stationary heater radio remote control receiver |
13L |
| A6/1 |
Stationary heater radio remote control receiver |
8L |
| A6b1 |
Stationary heater temperature sensor |
45A |
| A6f1 |
Stationary heater thermal fuse |
44A |
| A6m2 |
Stationary heater combustion air blower |
46C |
| A6n1 |
Stationary heater control unit |
16A |
| A6r4 |
Stationary heater glow plug/flame monitor unit |
43C |
| A6r5 |
Stationary heater fuel preheating system heating element |
43A |
| A6y1 |
Stationary heater switchover valve |
45C |
| CAN B |
Interior CAN |
38K |
| N10/2 |
Rear SAM control unit with fuse and relay module |
3L |
| N10/2 |
Rear SAM control unit with fuse and relay module |
30L |
| N10/2f73 |
Fuse 73 |
5L |
| N10/2f75 |
Fuse 75 |
2L |
| N10/2f82 |
Fuse 82 |
29L |
| U501 |
Valid for xenon headlamps |
41D |
| U679 |
Valid for version without xenon headlamps |
41E |
| U801 |
Valid for mobile phone preinstallation with universal interface |
17E |
| U957 |
Valid without mobile phone |
15E |
| W15/7 |
Right front footwell ground point |
2E |
| W15/7 |
Right front footwell ground point |
40H |
| W7/1 |
Right taillamp trunk ground point |
12H |
| W7/1 |
Right taillamp trunk ground point |
24H |
| W7/1 |
Right taillamp trunk ground point |
43H |
| W7/1 |
Right taillamp trunk ground point |
7H |
| X30/33 |
Right vehicle floor interior CAN voltage distributor electrical connector |
38L |
| X39/37 |
Mobile phone electrical connector |
28L |
| X62/33 |
Rear axle electrical connector, right distributor |
42H |
| Y16 |
Stationary heater switchover valve |
40L |
| Y23 |
Stationary heater fuel pump |
42L |
