| A0 |
Color code key |
56L |
| A38/1 |
Pedestrian protection Hall sensor + engine hood ATA [EDW] switch |
50A |
| A7/5 |
Soft top control hydraulic unit |
2L |
| Code 218 |
Backup camera |
28A |
| Code 359 |
TELEAID emergency call system |
44A |
| Code 494 |
USA version |
24F |
| Code 498 |
Japan version |
28A |
| Code 501 |
360 degree camera |
20A |
| Code 889 |
KEYLESS-GO |
40A |
| Code U60 |
Pedestrian protection |
48A |
| E17/18 |
Left rear footwell lamp |
42L |
| M40 |
Multicontour seat pneumatic pump |
19L |
| N123/4 |
Emergency call system control unit |
46A |
| N148 |
360° camera control unit |
22A |
| N29/5 |
Left front seat ventilation blower regulator |
36L |
| N29/6 |
Right front seat ventilation blower regulator |
39L |
| N40/3 |
Sound system amplifier control unit |
26A |
| N66/10 |
Backup camera voltage supply module |
31A |
| N66/2 |
Backup camera control unit |
32A |
| N69/5 |
KEYLESS-GO control unit |
42A |
| N70/3 |
Overhead control panel electronics |
26L |
| N70/3 |
Overhead control panel electronics |
30L |
| N87/3 |
Digital Audio Broadcasting control unit |
37A |
| N87/5 |
Satellite digital audio radio (SDAR) control unit |
37A |
| N87/8 |
SDAR control unit/high definition tuner |
38A |
| N88 |
Tire pressure monitor control unit |
22L |
| R22/5 |
Left AIRSCARF heating element |
16L |
| R22/5 |
Left AIRSCARF heating element |
17L |
| R22/6 |
Right AIRSCARF heating element |
17L |
| R22/6 |
Right AIRSCARF heating element |
16L |
| S52/8 |
Left head restraint "down" limit switch |
11L |
| S52/9 |
Right head restraint "down" limit switch |
12L |
| S68/5 |
Left rear seat belt buckle switch |
33L |
| S68/5x1 |
Left rear seat belt buckle switch electrical connector |
|
| S84/13 |
Soft top compartment cover switch group (open/close) |
6L |
| S84/15 |
Soft top bow "down/up" limit switch |
7L |
| S84/19 |
Soft top bow "locked" limit switch |
14L |
| S84/20 |
Ski bag "closed" limit switch |
8L |
| S84/22 |
Soft top compartment cover in catch position limit switch |
9L |
| S84/3 |
Soft top "open" limit switch |
3L |
| S84/9 |
Variable soft top compartment limit switch |
4L |
| U108 |
Valid for rear seat belt buckles |
32F |
| U112 |
Valid for footwell lamps |
41F |
| U12 |
Valid for left-hand drive vehicles |
15G |
| U12 |
Valid for left-hand drive vehicles |
41F |
| U12 |
Valid for left-hand drive vehicles |
48A |
| U13 |
Valid for right-hand drive vehicles |
15G |
| U141 |
Valid for Digital Audio Broadcasting |
34A |
| U172 |
Valid for high-definition tuner control unit |
34B |
| U23 |
Valid for convertibles |
28G |
| U23 |
Valid for convertibles |
1D |
| U23 |
Valid for convertibles |
15F |
| U23 |
Valid for convertibles |
20A |
| U23 |
Valid for convertibles |
32F |
| U23 |
Valid for convertibles |
40A |
| U438 |
Valid for seat ventilation |
34F |
| U512 |
Valid for electronic level control |
20G |
| U54 |
Valid for all except Japan |
28B |
| U611 |
Valid for Coupe |
24G |
| U611 |
Valid for Coupe |
32F |
| U645 |
Valid for tire pressure monitor |
20F |
| U749 |
Valid for multicontour seat |
18F |
| U778 |
Valid for heated seats and seat ventilation |
15F |
| U816 |
Valid for satellite digital audio radio (SDAR) |
34A |
| U90 |
Valid for sound system |
24A |
| U941 |
Valid without electronic level control |
20G |
| W18/3 |
Left front seat crossmember ground point 2 |
31E |
| X18/37 |
Emergency call system button electrical connector |
25J |
| X23/11 |
Electrical connector/soft top compartment lid |
13G |
| X23/15 |
Left roll-over protection system electrical connector |
10G |
| X23/16 |
Right roll-over protection system electrical connector |
11G |
| X55/3 |
Driver seat connector block |
15J |
| X55/3 |
Driver seat connector block |
17J |
| X55/3 |
Driver seat connector block |
35G |
| X55/3 |
Driver seat connector block |
42G |
| X55/4 |
Front passenger seat connector block |
15J |
| X55/4 |
Front passenger seat connector block |
17J |
| X55/4 |
Front passenger seat connector block |
39G |
| X62/32 |
Rear axle electrical connector, left distributor |
21J |
| Z6/42 |
Ground point connector sleeve W18/3 |
8E |
