| A0 |
Color code key |
40L |
| A40/3 |
COMAND control unit |
17L |
| A76 |
Left front reversible emergency tensioning retractor |
7A |
| B4/31 |
Fuel quality sensor |
14L |
| B48 |
Front passenger seat occupied recognition and ACSR |
32L |
| Code 929 |
Engine for ethanol fuel |
13F |
| E18/5 |
Left luggage compartment lamp |
2L |
| N15/5 |
Electronic selector lever module control unit |
3A |
| N22/6 |
Rear control unit |
6L |
| N32/1 |
Driver seat control unit |
14A |
| N37/5 |
Left NOx sensor control unit |
35L |
| N37/6 |
Right NOx sensor control unit |
37L |
| N69/1 |
Left front door control unit |
11A |
| R12/10 |
Front passenger sidebag squib |
33L |
| R12/41 |
Driver pelvis airbag squib |
20L |
| R12/42 |
Front passenger pelvis airbag squib |
20L |
| R12/9 |
Driver sidebag squib |
25L |
| R13/1 |
Left front seat sitting surface heated cushion |
12L |
| R13/2 |
Left front backrest heated cushion |
11L |
| R13/2x1 |
Left front backrest heater pad electrical connector |
11K |
| S22 |
Left front seat adjustment switch group |
24L |
| S22/1 |
Driver seat partially electric seat adjustment switch |
22L |
| S23 |
Right front seat adjustment switch group |
29L |
| S23/1 |
Front passenger seat partially electric seat adjustment switch |
27L |
| S54/5 |
Left rear backrest inclination switch |
9L |
| U12 |
Valid for left-hand drive vehicles |
19D |
| U12 |
Valid for left-hand drive vehicles |
21D |
| U13 |
Valid for right-hand drive vehicles |
19D |
| U13 |
Valid for right-hand drive vehicles |
26D |
| U157 |
Valid for combustion engine 272 DE |
34D |
| U2 |
Valid for all except USA |
30F |
| U21 |
Valid for heated seats |
10F |
| U25 |
Valid for automatic transmission |
1A |
| U284 |
Valid for fully electric seat adjustment |
23F |
| U284 |
Valid for fully electric seat adjustment |
28F |
| U285 |
Valid for partially electric driver seat adjustment |
21F |
| U286 |
Valid for partially electric front passenger seat adjustment |
26F |
| U611 |
Valid for Coupe |
4F |
| U775 |
Valid for emergency tensioning retractor |
5A |
| U781 |
Valid for left trunk lamp |
1F |
| U801 |
Valid for mobile phone preinstallation with universal interface |
2F |
| U804 |
Valid for rear backrest adjustment |
8F |
| U848 |
Valid for ACSR |
30F |
| U958 |
Valid for pelvis airbag |
19D |
| W18 |
Left front seat crossmember ground point |
13E |
| X173/1 |
Driver pelvis airbag electrical connector |
20G |
| X173/2 |
Front passenger pelvis airbag electrical connector |
20H |
| X28/18 |
ACSR [AKSE] seat occupied recognition electrical connector |
31G |
| X39/37 |
Mobile phone electrical connector |
3L |
| X55/3 |
Driver seat connector block |
10H |
| X55/3 |
Driver seat connector block |
20E |
| X55/3 |
Driver seat connector block |
22E |
| X55/3 |
Driver seat connector block |
25E |
| X55/4 |
Front passenger seat connector block |
20F |
| X55/4 |
Front passenger seat connector block |
27E |
| X55/4 |
Front passenger seat connector block |
31E |
| X75 |
Fuel quality sensor electrical connector |
14H |
| X86/1 |
Nitrogen oxides control unit electrical connector |
36E |
| X86/1 |
Nitrogen oxides control unit electrical connector |
34E |
| Z6/40 |
NOx sensor connector sleeve |
35G |
| Z6/94 |
Driver seat circuit 31 connector sleeve |
23G |
| Z6/95 |
Front passenger seat circuit 31 connector sleeve |
28G |
