| A0 |
Color code key |
48L |
| A28/13 |
Compensator/cellular telephone system UMTS |
20L |
| A6/1 |
Stationary heater radio remote control receiver |
16L |
| A6/1 |
Stationary heater radio remote control receiver |
18L |
| A86/2b1 |
Right outer radar sensor, rear bumper |
11L |
| A86/2b4 |
Left outer radar sensor, rear bumper |
13L |
| A90/1 |
TV tuner (analog/digital) |
26L |
| A90/3 |
TV digital tuner |
25L |
| Code 863 |
Digital/analog TV tuner |
24F |
| Code 865 |
TV tuner (digital) |
24G |
| Code B03 |
ECO start/stop function |
28F |
| E1 |
Left front lamp unit |
41L |
| E1 |
Left front lamp unit |
39L |
| E1/3 |
Left daytime running lamps headlamp |
35L |
| E18/4 |
Right luggage compartment lamp |
8L |
| E1m1 |
Left headlamp range adjustment actuator motor |
43L |
| E3 |
Left rear lamp unit |
9L |
| E4 |
Right rear lamp unit |
10L |
| E5/1 |
Left fog lamp |
37L |
| E6/3 |
Left rear side-marker lamp |
9L |
| E6/4 |
Right rear side-marker lamp |
10L |
| K114 |
ECO start/stop function additional battery relay |
29L |
| M4/7 |
Combustion engine and air conditioning with integrated control fan motor |
38A |
| N10/2 |
Rear SAM control unit with fuse and relay module |
4A |
| N10/2 |
Rear SAM control unit with fuse and relay module |
26A |
| N22/6 |
Rear control unit |
9A |
| N26/6 |
Interior protection and tow-away protection control unit |
2L |
| N28/1 |
Trailer recognition control unit |
31A |
| N88 |
Tire pressure monitor control unit |
14A |
| R2/10 |
Wiper park heater |
34L |
| U1018 |
Valid for gasoline engine 276 |
36B |
| U111 |
Valid for overhead control panel without CAN |
1D |
| U12 |
Valid for left-hand drive vehicles |
36F |
| U13 |
Valid for right-hand drive vehicles |
36F |
| U157 |
Valid for combustion engine 272 DE |
36A |
| U16 |
Valid for ATA [EDW] with tow-away protection and interior protection |
1D |
| U19 |
Valid for standard equipment |
36G |
| U2 |
Valid for all except USA |
42F |
| U23 |
Valid for convertibles |
7F |
| U23 |
Valid for convertibles |
8A |
| U23 |
Valid for convertibles |
24A |
| U248 |
Valid for headlamp range adjustment for halogen headlamps |
42G |
| U484 |
Valid for gasoline engine 273 |
36C |
| U501 |
Valid for xenon headlamps |
21F |
| U501 |
Valid for xenon headlamps |
38F |
| U533 |
Valid for trailer hitch |
29A |
| U579 |
Valid for stationary heater |
15F |
| U611 |
Valid for Coupe |
5A |
| U611 |
Valid for Coupe |
11A |
| U645 |
Valid for tire pressure monitor |
11A |
| U679 |
Valid for version without xenon headlamps |
21G |
| U679 |
Valid for version without xenon headlamps |
40F |
| U709 |
Valid for wiper park position heater |
33F |
| U739 |
Valid for gasoline engine 271 DE |
36A |
| U801 |
Valid for mobile phone preinstallation with universal interface |
20F |
| U819 |
Valid for gasoline engine 272 |
36C |
| U880 |
Valid for diesel engine 642 |
36B |
| U910 |
Valid for Blind Spot Assist |
11F |
| U948 |
Valid for diesel engine 651 |
36B |
| U971 |
Valid for daytime running lamps |
34F |
| W7/1 |
Right taillamp trunk ground point |
7E |
| W7/7 |
Right spare wheel well ground point |
27E |
| W9 |
Left front ground point (at lamp unit) |
38E |
| X172/2 |
Rear bumper radar sensors electrical connector |
14H |
| X18/2 |
Interior/roof electrical connector |
1H |
| X58 |
Trailer socket |
5L |
| X62/33 |
Rear axle electrical connector, right distributor |
22H |
| Y23 |
Stationary heater fuel pump |
23L |
| Z20/30z1 |
Tracer wire connector sleeve |
3J |
| Z20/30z2 |
Tracer wire connector sleeve |
3E |
| Z36/1 |
Rear PARKTRONIC sensors ground line connector sleeve |
12G |
