| A0 |
Color code key |
137L |
| A2/118 |
Windshield antenna |
37L |
| A2/118 |
Windshield antenna |
114L |
| A2/19 |
Rear window antenna FM antenna amplifier |
89L |
| A2/19 |
Rear window antenna FM antenna amplifier |
92L |
| A2/32 |
Rear window antenna |
108L |
| A2/54 |
TV 3, FM2 and DAB band III antenna amplifier |
23L |
| A2/54 |
TV 3, FM2 and DAB band III antenna amplifier |
49L |
| A2/89 |
TV antenna splitter |
45L |
| A2/89 |
TV antenna splitter |
27L |
| A28/11 |
Multifunction antenna |
30L |
| A28/11 |
Multifunction antenna |
95L |
| A40/3 |
COMAND control unit |
59L |
| A40/3 |
COMAND control unit |
122L |
| A40/3 |
COMAND control unit |
7L |
| A40/3 |
COMAND control unit |
16L |
| A40/3 |
COMAND control unit |
73L |
| A40/3 |
COMAND control unit |
81L |
| A90/4 |
Tuner unit |
4A |
| A90/4 |
Tuner unit |
12A |
| A90/4 |
Tuner unit |
45A |
| A90/4 |
Tuner unit |
28A |
| A90/4 |
Tuner unit |
53A |
| A90/4 |
Tuner unit |
61A |
| A90/4 |
Tuner unit |
125A |
| A90/4 |
Tuner unit |
117A |
| A90/4 |
Tuner unit |
101A |
| A90/4 |
Tuner unit |
85A |
| A90/4 |
Tuner unit |
69A |
| A90/4 |
Tuner unit |
20A |
| A90/4 |
Tuner unit |
36A |
| A90/4 |
Tuner unit |
109A |
| A90/4 |
Tuner unit |
77A |
| A90/4 |
Tuner unit |
93A |
| A94/1 |
TV 1 antenna amplifier |
33L |
| A94/10 |
TV 2, DAB band III and KEYLESS-GO antenna amplifier |
41L |
| A94/2 |
TV 2 and KEYLESS GO antenna amplifier |
112L |
| A94/3 |
TV 3 antenna amplifier |
117L |
| A94/5 |
TV 1 and DAB band III antenna |
88L |
| A94/5 |
TV 1 and DAB band III antenna |
99L |
| Code 536 |
SIRIUS satellite radio |
29E |
| Code 536 |
SIRIUS satellite radio |
93E |
| Code 537 |
Digital radio |
21E |
| Code 537 |
Digital radio |
86E |
| Code 537 |
Digital radio |
90E |
| Code 537 |
Digital radio |
25E |
| Code 810 |
Sound system |
10E |
| Code 810 |
Sound system |
75E |
| Code 865 |
TV tuner (digital) |
25E |
| Code 865 |
TV tuner (digital) |
31E |
| Code 865 |
TV tuner (digital) |
90E |
| Code 865 |
TV tuner (digital) |
96E |
| N10/2 |
Rear SAM control unit with fuse and relay module |
4L |
| N10/2 |
Rear SAM control unit with fuse and relay module |
69L |
| N10/2 |
Rear SAM control unit with fuse and relay module |
105L |
| N10/2 |
Rear SAM control unit with fuse and relay module |
55L |
| N10/2f85 |
Fuse 85 |
2L |
| N10/2f85 |
Fuse 85 |
68L |
| N40/3 |
Sound system amplifier control unit |
12L |
| N40/3 |
Sound system amplifier control unit |
77L |
| U23 |
Valid for convertibles |
1A |
| U500 |
Not valid for sound system |
6E |
| U500 |
Not valid for sound system |
71E |
| U611 |
Valid for Coupe |
66A |
| W7 |
Right wheelhouse trunk ground point |
69G |
| W7/7 |
Right spare wheel well ground point |
4G |
| Z35/10 |
MOST wake-up signal connector sleeve |
11G |
| Z35/10 |
MOST wake-up signal connector sleeve |
76G |
| Z4/23 |
Antenna circuit 30 connector sleeve |
102L |
| Z4/23 |
Antenna circuit 30 connector sleeve |
52L |
