| A0 |
Color code key |
48L |
| Code 359 |
TELEAID emergency call system |
28F |
| Code 810 |
Sound system |
32F |
| H4/1 |
Left door speaker |
16L |
| H4/1h1 |
Left door tweeter |
17L |
| H4/1h2 |
Left door bass speaker |
15L |
| H4/2 |
Right door speaker |
19L |
| H4/27 |
Center instrument panel speaker |
26L |
| H4/29 |
Rear shelf bass speaker |
8L |
| H4/29 |
Rear shelf bass speaker |
13L |
| H4/29x1 |
Bass speaker electrical connector |
6J |
| H4/29x1 |
Bass speaker electrical connector |
12J |
| H4/2h1 |
Right door tweeter |
19L |
| H4/2h2 |
Right door bass speaker |
18L |
| H4/3 |
Left rear speaker |
23L |
| H4/3h1 |
Left rear tweeter |
24L |
| H4/3h2 |
Left rear bass speaker |
23L |
| H4/4 |
Right rear speaker |
21L |
| H4/4h1 |
Right rear tweeter |
22L |
| H4/4h2 |
Right rear bass speaker |
21L |
| H4/54 |
Left rear surround speaker |
6L |
| H4/54 |
Left rear surround speaker |
10L |
| H4/55 |
Right rear surround speaker |
11L |
| H4/57 |
Right rear surround speaker |
7L |
| MOST |
Media Oriented System Transport |
39K |
| N10/2 |
Rear SAM control unit with fuse and relay module |
3L |
| N10/2f67 |
Fuse 67 |
2L |
| N112/2 |
Telematics services communication module |
34L |
| N123/4 |
Emergency call system control unit |
30L |
| N40/3 |
Sound system amplifier control unit |
4A |
| N40/3 |
Sound system amplifier control unit |
12A |
| N40/3 |
Sound system amplifier control unit |
20A |
| N40/3 |
Sound system amplifier control unit |
28A |
| N40/3 |
Sound system amplifier control unit |
36A |
| N40/3 |
Sound system amplifier control unit |
41A |
| U23 |
Valid for convertibles |
9E |
| U611 |
Valid for Coupe |
5E |
| W18/3 |
Left front seat crossmember ground point 2 |
3E |
| X18 |
Vehicle interior and harness for taillamp electrical connector |
25H |
| X23/11 |
Electrical connector/soft top compartment lid |
10H |
| X35/1 |
Left front door electrical connector |
15H |
| X35/2 |
Right front door electrical connector |
17H |
| Z35/10 |
MOST wake-up signal connector sleeve |
37E |
