| A0 |
Color code key |
56L |
| A17/3 |
Left rear KEYLESS GO door handle |
18L |
| A2 |
Radio |
23A |
| A2 |
Radio |
23A |
| A2 |
Radio |
38A |
| A2/39 |
Left rear door KEYLESS GO antenna |
16L |
| A2/56 |
Radio with auto pilot system |
23A |
| A40/3 |
COMAND control unit |
29A |
| A40/3 |
COMAND control unit |
38A |
| A85/3 |
Left rear door lock |
1L |
| A85/3s1 |
Left rear door rotary tumbler switch |
2L |
| B48/9 |
Left rear door pressure sensor |
13L |
| CAN B |
Interior CAN |
7B |
| Code 505 |
Radio 20 NTG5, non-navigation-capable |
35B |
| Code 522 |
Audio 20 radio |
35B |
| Code 531 |
COMAND APS |
35A |
| Code 810 |
Sound system |
31H |
| Code 810 |
Sound system |
31A |
| Code 811 |
Extended sound system |
41A |
| Code 889 |
KEYLESS-GO |
14A |
| H4/3 |
Left rear door speaker |
29L |
| H4/3 |
Left rear door speaker |
49L |
| H4/3h1 |
Left rear door tweeter |
30L |
| H4/70 |
Left rear door sound system tweeter |
33L |
| H4/70 |
Left rear door sound system tweeter |
50L |
| H4/80 |
Left rear door sound system midrange speaker |
32L |
| N10/2 |
Rear SAM control unit with fuse and relay module |
3A |
| N2/10 |
Supplemental restraint system control unit |
11A |
| N40/3 |
Sound system amplifier control unit |
33A |
| N40/3 |
Sound system amplifier control unit |
47A |
| N40/9 |
Rear bass speaker amplifier |
44A |
| N40/9 |
Rear bass speaker amplifier |
52A |
| N69/3 |
Left rear door control unit |
5L |
| N69/5 |
KEYLESS-GO control unit |
17A |
| U1014 |
Valid for Great Britain |
1H |
| U500 |
Not valid for sound system |
28H |
| U500 |
Not valid for sound system |
19A |
| U500 |
Not valid for sound system |
25A |
| U52 |
Valid for Japan |
25B |
| U54 |
Valid for all except Japan |
25B |
| U596 |
Valid for rear sidebag |
9A |
| U631 |
Valid for COMAND |
26A |
| U865 |
Valid for Audio 20 |
19B |
| U865 |
Valid for Audio 20 |
19B |
| U866 |
Valid for Audio 50 |
19B |
| W18 |
Left front seat crossmember ground point |
2E |
| X30/32 |
Left vehicle floor interior CAN voltage distributor electrical connector |
7A |
| X35/3 |
Left rear door electrical connector |
1G |
