| A0 |
Color code key |
72L |
| A32 |
AC housing |
51L |
| A32m1 |
Blower motor |
54L |
| A32m1x1 |
Blower motor electrical connector |
53J |
| A32n1 |
Blower regulator |
52L |
| A32x1 |
Air conditioner housing electrical connector |
51J |
| A32z1 |
Air conditioner housing connector sleeve |
52H |
| A6 |
Stationary heater unit |
57L |
| Code 228 |
Stationary heater |
55F |
| Code 421 |
9-speed automatic transmission |
40F |
| Code 488 |
Steel/air suspension |
37G |
| Code 489 |
AIRMATIC (air suspension with continuously adjustable damping) |
37F |
| Code 4U7 |
Start/stop voltage dip protection |
1B |
| Code 4U7 |
Start/stop voltage dip protection |
23B |
| Code 4U7 |
Start/stop voltage dip protection |
34A |
| Code 4U7 |
Start/stop voltage dip protection |
37B |
| Code 4U7 |
Start/stop voltage dip protection |
66A |
| Code 580 |
Air conditioning |
49G |
| Code 581 |
Automatic air conditioning |
49G |
| Code B03 |
ECO start/stop function |
1A |
| Code B03 |
ECO start/stop function |
23A |
| Code B03 |
ECO start/stop function |
37A |
| Code B03 |
ECO start/stop function |
59A |
| F32 |
Front electrical prefuse box |
4A |
| F32 |
Front electrical prefuse box |
12A |
| F32 |
Front electrical prefuse box |
20A |
| F32 |
Front electrical prefuse box |
28A |
| F32 |
Front electrical prefuse box |
34A |
| F32 |
Front electrical prefuse box |
44A |
| F32 |
Front electrical prefuse box |
52A |
| F32 |
Front electrical prefuse box |
61A |
| F32 |
Front electrical prefuse box |
68A |
| F32c1 |
Interference suppression capacitor |
36A |
| F32f150 |
Pyrofuse 150 |
18C |
| F32f150/1 |
Prefuse 150 |
|
| F32f150/1 |
Prefuse 150 |
|
| F32f151 |
Prefuse 151 |
26C |
| F32f151 |
Prefuse 151 |
28C |
| F32f152 |
Prefuse 152 |
32C |
| F32f153 |
Prefuse 153 |
6C |
| F32f154 |
Prefuse 154 |
5C |
| F32f154 |
Prefuse 154 |
28C |
| F32f155 |
Prefuse 155 |
32C |
| F32f156 |
Prefuse 156 |
4C |
| F32f156 |
Prefuse 156 |
6C |
| F32f157 |
Prefuse 157 |
5C |
| F32f157 |
Prefuse 157 |
26C |
| F32f158 |
Prefuse 158 |
7C |
| F32f158 |
Prefuse 158 |
50C |
| F32f159 |
Prefuse 159 |
8C |
| F32f159 |
Prefuse 159 |
47C |
| F32f160 |
Prefuse 160 |
38C |
| F32f160 |
Prefuse 160 |
49C |
| F32f161 |
Prefuse 161 |
47C |
| F32f162 |
Prefuse 162 |
4C |
| F32f162 |
Prefuse 162 |
38C |
| F32f163 |
Prefuse 163 |
7C |
| F32f164 |
Prefuse 164 |
8C |
| F32k2 |
Quiescent current cutout relay |
11A |
| F34 |
Interior fuse box |
58J |
| F34f116 |
Fuse 116 |
58H |
| K67 |
AIRMATIC relay |
38L |
| M4/7 |
Combustion engine and air conditioning with integrated control fan motor |
29L |
| N10/1 |
Front SAM control unit with fuse and relay module |
5L |
| N10/2 |
Rear SAM control unit with fuse and relay module |
10L |
| N2/10 |
Supplemental restraint system control unit |
14L |
| N30/4 |
Electronic Stability Program control unit |
47L |
| N30/4 |
Electronic Stability Program control unit |
47L |
| N30/7 |
Premium Electronic Stability Program control unit |
46L |
| N30/7 |
Premium Electronic Stability Program control unit |
48L |
| N68 |
Electrical power steering control unit |
25L |
| R22/3 |
PTC heater booster |
33L |
| U1018 |
Valid for gasoline engine 276 |
20H |
| U1019 |
Valid for gasoline engine 278 |
17J |
| U1028 |
Valid for engine 157 |
17J |
| U113 |
Valid for 2-zone THERMATIC |
31G |
| U114 |
Valid for 3-zone THERMOTRONIC |
31G |
| U12 |
Valid for left-hand drive vehicles |
35F |
| U12 |
Valid for left-hand drive vehicles |
49F |
| U13 |
Valid for right-hand drive vehicles |
35G |
| U240 |
Valid for all except ECO start/stop function |
13A |
| U240 |
Valid for all except ECO start/stop function |
34A |
| U240 |
Valid for all except ECO start/stop function |
1B |
| U240 |
Valid for all except ECO start/stop function |
23B |
| U240 |
Valid for all except ECO start/stop function |
37B |
| U242 |
Valid for fan motor 800 W |
27G |
| U250 |
Valid for electric power steering |
23F |
| U362 |
Valid for gasoline engine 274 |
20J |
| U437 |
Valid without code (4U7) Start/stop voltage dip protection |
1A |
| U437 |
Valid without code (4U7) Start/stop voltage dip protection |
24A |
| U437 |
Valid without code (4U7) Start/stop voltage dip protection |
37A |
| U437 |
Valid without code (4U7) Start/stop voltage dip protection |
60A |
| U576 |
Valid for heater booster |
31F |
| U880 |
Valid for diesel engine 642 |
9G |
| U880 |
Valid for diesel engine 642 |
17H |
| U938 |
Valid for ESP Basic |
44F |
| U938 |
Valid for ESP Basic |
44G |
| U939 |
Valid for ESP Premium |
44G |
| U939 |
Valid for ESP Premium |
45G |
| U948 |
Valid for diesel engine 651 |
20J |
| U950 |
Valid for fan motor 650 W |
27F |
| V19 |
ECO start/stop function diode |
62C |
| W16/3 |
Left major assembly compartment ground point |
36L |
| W16/4 |
Right wheelhouse ground point |
36L |
| X18 |
Vehicle interior and harness for taillamp electrical connector |
56H |
| X18 |
Vehicle interior and harness for taillamp electrical connector |
51H |
| X85/8 |
PTC heater booster electrical connector |
32H |
| Y3/8 |
Fully integrated transmission control unit |
42L |
| Z211z1 |
Circuit 30 supply line connector sleeve |
38H |
| Z211z2 |
Circuit 30 supply line connector sleeve |
38J |
| Z211z4 |
Circuit 30 supply line connector sleeve |
42H |
