| A0 |
Color code key |
56L |
| A2 |
Radio |
5A |
| A2 |
Radio |
5A |
| A2 |
Radio |
16A |
| A2/56 |
Radio with auto pilot system |
5A |
| A40/3 |
COMAND control unit |
11A |
| A40/3 |
COMAND control unit |
16A |
| B48/7 |
Left front door pressure sensor |
24L |
| B48/8 |
Right front door pressure sensor |
33L |
| Code 505 |
Radio 20 NTG5, non-navigation-capable |
13B |
| Code 522 |
Audio 20 radio |
13B |
| Code 531 |
COMAND APS |
13A |
| Code 810 |
Sound system |
12H |
| Code 810 |
Sound system |
28H |
| Code 810 |
Sound system |
19A |
| Code 811 |
Extended sound system |
34A |
| H4/1 |
Left front door speaker |
10L |
| H4/1 |
Left front door speaker |
41L |
| H4/1h1 |
Left front door tweeter |
11L |
| H4/2 |
Right front door speaker |
26L |
| H4/2 |
Right front door speaker |
42L |
| H4/2h1 |
Right front door tweeter |
27L |
| H4/64 |
Left front door sound system bass speaker |
21L |
| H4/64 |
Left front door sound system bass speaker |
45L |
| H4/65 |
Right front door sound system bass speaker |
31L |
| H4/65 |
Right front door sound system bass speaker |
46L |
| H4/68 |
Left front door sound system tweeter |
15L |
| H4/69 |
Right front door sound system tweeter |
30L |
| H4/72 |
Left front door sound system midrange speaker |
14L |
| H4/73 |
Right front door sound system midrange speaker |
29L |
| N2/10 |
Supplemental restraint system control unit |
25A |
| N2/10 |
Supplemental restraint system control unit |
32A |
| N40/3 |
Sound system amplifier control unit |
21A |
| N40/3 |
Sound system amplifier control unit |
38A |
| N40/3 |
Sound system amplifier control unit |
47A |
| N40/9 |
Rear bass speaker amplifier |
41A |
| U500 |
Not valid for sound system |
10H |
| U500 |
Not valid for sound system |
25H |
| U500 |
Not valid for sound system |
1A |
| U500 |
Not valid for sound system |
7A |
| U52 |
Valid for Japan |
7B |
| U54 |
Valid for all except Japan |
7B |
| U631 |
Valid for COMAND |
8A |
| U865 |
Valid for Audio 20 |
1B |
| U865 |
Valid for Audio 20 |
1B |
| U866 |
Valid for Audio 50 |
1B |
| X35/1 |
Left front door electrical connector |
11H |
| X35/1 |
Left front door electrical connector |
40G |
| X35/1 |
Left front door electrical connector |
44G |
| X35/2 |
Right front door electrical connector |
26H |
| X35/2 |
Right front door electrical connector |
42G |
| X35/2 |
Right front door electrical connector |
46G |
