Remove/install cover for loudspeaker - AR68.10-P-1050RK

MODEL 231

Fig 1: Cover For Loudspeaker Remove/Install Components

Courtesy of MERCEDES-BENZ USA

	Remove/install
1	Switch off ignition and remove transmitter key (A8/1) or KEYLESS-GO start/stop button (S2/3) from electronic ignition lock control unit (N73)	KEYLESS-GO start/stop button (S2/3) only with code (889) KEYLESS-GO.
2	Unclip cover (1) on clips (4) from instrument (2) with long wedge (3)	First unclip cover (1) at rear. First insert cover (1) at front into instrument panel (2). Long wedge	Fig 2
3	Disconnect electrical connector (5) from analog clock (A70/1)	With CODE 246 (analog clock) Adjust time on analog clock (A70/1).
4	Disconnect electrical connector (6) from front parking system warning indicator (A44/1)	With code (235) Active Parking Assist
5	Disconnect electrical connector (7) from sun sensor (B32/3)
6	Remove cover (1)
7	Install in the reverse order

Fig 2: Identifying Long Wedge (115 589 03 59 00)

Courtesy of MERCEDES-BENZ USA
