| A0 |
Color code key |
80L |
| B95 |
Battery sensor |
63L |
| Code 430 |
On-road/off-road package |
20J |
| Code 430 |
On-road/off-road package |
24H |
| Code 489 |
AIRMATIC |
20H |
| Code 550 |
Trailer hitch |
57G |
| Code B03 |
ECO start/stop function |
48G |
| Code ME05 |
HYBRID DRIVE 80 KW VARIANT (INCLUDING PLUGIN) |
52G |
| F32/4 |
Interior prefuse box |
4L |
| F32/4f250 |
Fuse 250 |
1K |
| F32/4f251 |
Fuse 251 |
3K |
| F32/4f252 |
Fuse 252 |
4K |
| M14/10 |
Tank cap central locking actuator |
70L |
| M5/1 |
Windshield washer system pump |
40L |
| M6/1 |
Wiper motor |
46L |
| N10 |
SAM control unit |
4A |
| N10 |
SAM control unit |
12A |
| N10 |
SAM control unit |
20A |
| N10 |
SAM control unit |
28A |
| N10 |
SAM control unit |
36A |
| N10 |
SAM control unit |
44A |
| N10 |
SAM control unit |
52A |
| N10 |
SAM control unit |
60A |
| N10 |
SAM control unit |
68A |
| N2/10 |
Supplemental restraint system control unit |
67L |
| N28/1 |
Trailer recognition control unit |
58L |
| N30/4 |
Electronic Stability Program control unit |
54L |
| N32/1 |
Driver seat control unit |
13L |
| N32/2 |
Front passenger seat control unit |
17L |
| N70 |
Overhead control panel control unit |
10L |
| N72 |
Lower control panel control unit |
22L |
| N72/1 |
Upper control panel control unit |
30L |
| N72/3 |
Off-Road operating panel control unit |
26L |
| N72/4 |
Transmission modes control panel |
26L |
| S10/2 |
Right front brake wear sensor |
43L |
| S10/2x1 |
Right front brake wear sensor electrical connector |
43J |
| S62/42 |
Right engine hood contact switch |
51L |
| U12 |
Valid for left-hand drive vehicles |
5G |
| U13 |
Valid for right-hand drive vehicles |
4G |
| U437 |
Not valid for code 4U7 Start/stop voltage dip protection |
48G |
| U557 |
Not valid for on-road/off-road package |
24J |
| U63 |
Valid for seat adjustment without memory function |
14H |
| U63 |
Valid for seat adjustment without memory function |
18H |
| U74 |
Valid for diesel engines |
61H |
| U75 |
Valid for gasoline engines |
61G |
| U974 |
Not valid for hybrid drive |
52H |
| W15/5 |
Left front footwell ground point |
5J |
| W18/5 |
Roof ground point |
5H |
| W2 |
Right front ground point at lamp unit |
41J |
| W52/11 |
Upper right front longitudinal member ground point |
49K |
| W7 |
Right rear center section ground point |
70H |
| X174/4 |
Engine compartment/vehicle front electrical connector |
50J |
| X29/6 |
Center console electrical connector |
21H |
| X30/4 |
Right potential distributor electrical connector (CAN) |
37L |
| X30/6 |
Cockpit potential distributor electrical connector (CAN) |
33L |
| X62/36 |
BWI [BBV]/rpm right front axle electrical connector |
43H |
