Reception Report For Service At Vehicle - AP00.20-P-0009Z
Model 117, 118, 156, 164, 166, 167, 169, 171, 172, 176, 177, 190, 197.3/4, 203, 204, 205, 207, 209, 211, 212, 213, 216, 217, 218, 219, 221, 222, 223, 230, 231, 238, 242, 243, 245, 246, 247, 251, 253, 257, 290, 292, 293, 461, 463
| M | Input condition not OK: | ⓧ | ||
|---|---|---|---|---|
| Completed | ||||
| √ | ||||
| ↓ | ↓ | |||
| □ | Vehicle general Check before driving into working area. |
Model 253.99 | ◦ | AP00.20-P-0062U |
| □ | Check condition of vehicle exterior. | ◦ | AP60.00-P-6048U | |
| □ | Check condition of windshield. | ◦ | AP67.10-P-6750A | |
| □ | Check condition of wiper blades. | ◦ | AP82.30-P-8248U | |
| □ | Check condition of vehicle underside (optional). | ◦ | AP60.00-P-6049U | |
| □ | Check main circuit coolant level. | ◦ | AP20.30-P-2049U | |
| □ | Assess condition/tire tread depth. | ◦ | AP40.10-P-4047U | |
| □ | Assess condition of brake pads. | ◦ | AP42.10-P-4248U | |
| □ | Assess condition of brake disks. | ◦ | AP42.10-P-4249U | |
| □ | Check lamps in instrument cluster. | ◦ | AP54.30-P-5449U | |
| □ | Check horn for proper operation. | ◦ | ||
| □ | Read out and reset service. | AP00.20-P-0049U | ||
| □ | Map data status, check update. | AP82.85-P-8249U | ||
| □ | Vehicle/customer-specific Plus package. |
□ Yes □No | AP00.20-P-0048U | |
| □ | Additional operation, "Fill with AdBlue®". | □ Yes □No | AP00.20-P-0059U | |
| □ | Additional operation "Replace key battery". | □ Yes □No | ||
| □ | Additional operation - "Replace the dust filter". | □ Yes □No | AP00.20-P-0047U | |
| □ | Additional operation - "Driving aids ex-factory". | □ Yes □No | AP00.20-P-0047U | |
| □ | Additional operation "Fill up/replace flacon". | □ Yes □No | AP00.20-P-0059U | |
| □ | Additional operations "Gas drive system". | □ Yes □No Model 253.99 |
AP00.20-P-0047U | |
| □ | Additional operations - "Special protection vehicles". | □ Yes □No |
Remarks
