Perform Delivery Check For New Vehicles - AP00.20-P-1101A

Model 117, 118, 156, 166, 167, 172, 176, 177, 205, 206, 213, 217, 222, 223, 231, 238, 243, 247, 253, 257, 290, 292, 293, 461, 463

Courtesy of MERCEDES-BENZ USA

		Input condition not OK:	ⓧ
Completed
√
↓			↓
□	Vehicle exterior, body  Check windows, paint, chrome parts and plastic parts for shipping damage.		◦
□	Check condition of vehicle underside in front and rear area for shipping damage.		◦
□	Check condition of vehicle underside in area of high-voltage battery as well as front and rear underbody paneling for damage.	Model 243, 293 If necessary, use commercially available devices/tools.  Swiveling underbody inspection mirror with illumination. If problems are determined, ↓ Place vehicle on vehicle lift and check problems again. After obtaining special order.	◦
□	Tires, wheels  Check tires and rims for shipping damage.		◦
□	Vehicle interior  Check vehicle interior for damage and condition.		◦
□	Check charge level of high-voltage battery.	Vehicle with high-voltage battery. If the charge level (SOC) of the high-voltage battery is < 30 %, ↓ charge the high-voltage battery to an SOC value of ≥ 50 %.	◦
□	Check navigation system for completeness.		◦
□	Miscellaneous  Enter any other faults into table.
