| 1 |
Circuit 15, status |
7E |
| 10 |
Door rotary tumbler switch, status |
11F |
| 10 |
Door rotary tumbler switch, status |
15J |
| 11 |
Engine hood contact switch, status |
8G |
| 11 |
Engine hood contact switch, status |
7K |
| 2 |
Combination switch, status |
1B |
| 2 |
Combination switch, status |
8D |
| 2 |
Combination switch, status |
3G |
| 3 |
Wiper motor, actuation |
10C |
| 4 |
Rain/light sensor, status |
7G |
| 5 |
Circuit 50, status |
7E |
| 6 |
Vehicle speed, signal |
10G |
| 7 |
Selector lever position, status |
10E |
| 7 |
Selector lever position, status |
17B |
| 8 |
Gear range, status |
17C |
| 8 |
Gear range, status |
10E |
| 9 |
Clutch pedal switch, status |
10D |
| 9 |
Clutch pedal switch, status |
17F |
| A1 |
Instrument cluster |
10J |
| A38/1 |
Pedestrian protection Hall sensor + engine hood ATA [EDW] switch |
5H |
| A85 |
Left front door lock |
18G |
| A85/1 |
Right front door lock |
18H |
| A85/1s1 |
Right front door rotary tumbler switch |
18H |
| A85s1 |
Left front door rotary tumbler switch |
18H |
| B38/2 |
Rain/light sensor |
2G |
| CAN B |
Interior CAN |
10H |
| CAN B |
Interior CAN |
8H |
| CAN B |
Interior CAN |
12G |
| CAN B |
Interior CAN |
5F |
| CAN C |
Drive train CAN |
18B |
| CAN C |
Drive train CAN |
18D |
| CAN E |
Chassis CAN |
12D |
| CAN E |
Chassis CAN |
7C |
| CAN E1 |
Chassis CAN 1 |
12D |
| CAN E1 |
Chassis CAN 1 |
7C |
| Code 423 |
5-speed automatic transmission |
21A |
| Code 551 |
Anti-theft alarm system (ATA [EDW]) |
3H |
| Code 551 |
Anti-theft alarm system (ATA [EDW]) |
4H |
| LIN 2 |
Wiper/inside rearview mirror LIN |
9D |
| LIN 2 |
Wiper/inside rearview mirror LIN |
5G |
| M6/1 |
Wiper motor |
9B |
| N10/1 |
Front SAM control unit with fuse and relay module |
9E |
| N10/2 |
Rear SAM control unit with fuse and relay module |
8J |
| N15/5 |
Electronic selector lever module control unit |
21B |
| N3/10 |
ME-SFI [ME] control unit |
15D |
| N3/9 |
CDI control unit |
15A |
| N69/1 |
Left front door control unit |
14H |
| N69/2 |
Right front door control unit |
14H |
| N73 |
Electronic ignition switch control unit |
3D |
| N80 |
Steering column module control unit |
3A |
| S4 |
Combination switch |
1B |
| S40/3 |
Clutch pedal switch |
19E |
| S62/43 |
Left engine hood contact switch |
3H |
| U1510 |
Valid for transmission 722.9 |
21D |
| U24 |
Valid for manual transmission |
18E |
| U265 |
Not valid for pedestrian protection |
3H |
| U398 |
Valid for transmission 725 (NAG3) |
21D |
| U74 |
Valid for diesel engines |
13A |
| U75 |
Valid for gasoline engines |
13D |
| U956 |
Valid for pedestrian protection |
4H |
| Y3/8n4 |
Fully integrated transmission control control unit |
22D |
