| 1 |
Circuit 15, status |
11E |
| 10 |
High beam indicator lamp, actuation |
9K |
| 11 |
Daytime running lights, request |
11H |
| 12 |
Engine running, signal |
12G |
| 13 |
Drivetrain operational, signal |
12H |
| 14 |
Wheel speed, signal |
9F |
| 14 |
Wheel speed, signal |
17E |
| 14 |
Wheel speed, signal |
28E |
| 15 |
Vehicle speed, signal |
11H |
| 15 |
Vehicle speed, signal |
17E |
| 15 |
Vehicle speed, signal |
28E |
| 16 |
Daytime running lights, actuation |
21F |
| 16 |
Daytime running lights, actuation |
24F |
| 17 |
Rain/light sensor, status |
9E |
| 18 |
Level sensor, status |
29D |
| 18 |
Level sensor, status |
9E |
| 18 |
Level sensor, status |
4B |
| 18 |
Level sensor, status |
28F |
| 19 |
Synchronization, signal |
17C |
| 2 |
Exterior lights switch, status |
9D |
| 2 |
Exterior lights switch, status |
12D |
| 20 |
Headlamp range adjustment actuator motor, actuation |
18D |
| 20 |
Headlamp range adjustment actuator motor, actuation |
26D |
| 3 |
Low beams, actuation |
27E |
| 3 |
Low beams, actuation |
18E |
| 4 |
Xenon bulb with integrated ignition module, actuation |
19D |
| 4 |
Xenon bulb with integrated ignition module, actuation |
25D |
| 5 |
Low beams indicator lamp, request |
10J |
| 6 |
Low beams indicator lamp, actuation |
12K |
| 7 |
Combination switch, status |
5J |
| 7 |
Combination switch, status |
9G |
| 7 |
Combination switch, status |
17E |
| 7 |
Combination switch, status |
28E |
| 8 |
Light distribution actuator motor, actuation |
19D |
| 8 |
Light distribution actuator motor, actuation |
26D |
| 9 |
High beams, status |
11J |
| A1 |
Instrument cluster |
10K |
| A1e3 |
High beam indicator lamp |
9J |
| A1e67 |
Low beam indicator lamp |
12J |
| B22/10 |
Right rear level sensor |
5B |
| B22/7 |
Left rear level sensor |
31D |
| B22/7 |
Left rear level sensor |
5A |
| B22/8 |
Left front level sensor |
31D |
| B22/8 |
Left front level sensor |
5A |
| B22/9 |
Right front level sensor |
5B |
| B38/2 |
Rain/light sensor |
5D |
| CAN B |
Interior CAN |
10H |
| CAN B |
Interior CAN |
10D |
| CAN E |
Chassis CAN |
7H |
| CAN E |
Chassis CAN |
13H |
| CAN E |
Chassis CAN |
2G |
| CAN E |
Chassis CAN |
2D |
| CAN G |
Front end CAN |
13G |
| CAN G |
Front end CAN |
22A |
| CAN G |
Front end CAN |
22G |
| CAN G |
Front end CAN |
13F |
| Code 483 |
Vehicle dynamics package |
1A |
| E1 |
Left front lamp unit |
24C |
| E1/3 |
Left daytime running lamps headlamp |
23E |
| E1e10 |
Left xenon bulb with integrated ignition module |
24D |
| E1m1 |
Left headlamp range adjustment actuator motor |
24D |
| E1m3 |
Left light distribution actuator motor |
24D |
| E1n1 |
Left xenon lamp control unit |
27C |
| E2 |
Right front lamp unit |
20C |
| E2/3 |
Right daytime running lamps headlamp |
21E |
| E2e10 |
Right xenon bulb with integrated ignition module |
20D |
| E2m1 |
Right headlamp range adjustment actuator motor |
20D |
| E2m3 |
Right light distribution actuator motor |
20D |
| E2n1 |
Right xenon light control unit |
16C |
| LIN 1 |
Instrument panel LIN |
8C |
| LIN 2 |
Wiper/inside rearview mirror LIN |
7E |
| N10/1 |
Front SAM control unit with fuse and relay module |
11E |
| N3/10 |
ME-SFI [ME] control unit |
17J |
| N3/9 |
CDI control unit |
15J |
| N30/4 |
Electronic Stability Program control unit |
2J |
| N30/7 |
Premium Electronic Stability Program control unit |
2J |
| N51/5 |
Adaptive damping system control unit |
2B |
| N73 |
Electronic ignition switch control unit |
11A |
| N80 |
Steering column module control unit |
7H |
| S1 |
Exterior lights switch |
7B |
| S1 |
Exterior lights switch |
13B |
| S4 |
Combination switch |
5H |
| U203 |
Valid without DISTRONIC PLUS |
1H |
| U225 |
Valid without code 483 Vehicle dynamics package |
30C |
| U23 |
Valid for convertibles |
12A |
| U54 |
Valid for all except Japan |
20E |
| U54 |
Valid for all except Japan |
23E |
| U611 |
Valid for Coupe |
12B |
| U611 |
Valid for Coupe |
6A |
| U74 |
Valid for diesel engines |
14J |
| U75 |
Valid for gasoline engines |
16J |
| U909 |
Valid for DISTRONIC PLUS |
1H |
