| A0 |
Color code key |
40L |
| CAN B |
Interior CAN |
8K |
| CAN B |
Interior CAN |
27K |
| M94 |
Left front seat massage function actuator motor |
11L |
| M94x1 |
Left front seat massage function actuator motor electrical connector |
10H |
| M95 |
Right front seat massage function actuator motor |
30L |
| M95x1 |
Right front seat massage function actuator motor electrical connector |
28H |
| N10/2 |
Rear SAM control unit with fuse and relay module |
3L |
| N10/2 |
Rear SAM control unit with fuse and relay module |
22L |
| N10/2f62 |
Fuse 62 |
2L |
| N10/2f62 |
Fuse 62 |
21L |
| N10/2f64 |
Fuse 64 |
2L |
| N10/2f64 |
Fuse 64 |
21L |
| N32/1 |
Driver seat control unit |
7L |
| N32/1 |
Driver seat control unit |
26L |
| N32/19 |
Left front active multicontour seat control unit |
12A |
| N32/19 |
Left front active multicontour seat control unit |
18A |
| N32/2 |
Front passenger seat control unit |
7L |
| N32/2 |
Front passenger seat control unit |
26L |
| N32/22 |
Right front active multicontour seat control unit |
28A |
| N32/22 |
Right front active multicontour seat control unit |
35A |
| S108 |
Front passenger active multicontour seat button group |
16L |
| S108 |
Front passenger active multicontour seat button group |
35L |
| S108s1 |
Massage function button |
18L |
| S108s1 |
Massage function button |
36L |
| S108s2 |
Front passenger seat side bolster air cushion adjustment button |
15L |
| S108s2 |
Front passenger seat side bolster air cushion adjustment button |
33L |
| S108s3 |
Lumbar support +/- adjustment button |
16L |
| S108s3 |
Lumbar support +/- adjustment button |
34L |
| S108s4 |
Lumbar support up/down adjustment button |
17L |
| S108s4 |
Lumbar support up/down adjustment button |
35L |
| S108s5 |
Seat cushion length button |
18L |
| S108s5 |
Seat cushion length button |
37L |
| S108s6 |
Dynamic button |
14L |
| S108s6 |
Dynamic button |
32L |
| S109 |
Driver active multicontour seat button group |
16L |
| S109 |
Driver active multicontour seat button group |
35L |
| S109s1 |
Massage function button |
18L |
| S109s1 |
Massage function button |
36L |
| S109s2 |
Driver seat side bolster air cushion adjustment button |
15L |
| S109s2 |
Driver seat side bolster air cushion adjustment button |
33L |
| S109s3 |
Lumbar support +/- adjustment button |
16L |
| S109s3 |
Lumbar support +/- adjustment button |
34L |
| S109s4 |
Lumbar support up/down adjustment button |
17L |
| S109s4 |
Lumbar support up/down adjustment button |
35L |
| S109s5 |
Seat cushion length button |
19L |
| S109s5 |
Seat cushion length button |
37L |
| S109s6 |
Dynamic button |
14L |
| S109s6 |
Dynamic button |
32L |
| U12 |
Valid for left-hand drive vehicles |
1A |
| U13 |
Valid for right-hand drive vehicles |
1A |
| W18 |
Left front seat crossmember ground point |
6G |
| W19 |
Right front seat crossmember ground point |
25G |
