| A0 |
Color code key |
48L |
| A50/3 |
Electronic Toll Collection control unit |
20L |
| B40 |
Oil sensor (oil level, temperature and quality) |
37A |
| Code 443 |
Steering wheel heater |
2F |
| Code 551 |
Anti-theft alarm system (ATA [EDW]) |
5F |
| Code 551 |
Anti-theft alarm system (ATA [EDW]) |
24F |
| Code 551 |
Anti-theft alarm system (ATA [EDW]) |
22F |
| Code B03 |
ECO start/stop function |
5G |
| Code B03 |
ECO start/stop function |
24G |
| H3/1 |
Alarm siren |
23L |
| N25/7 |
Steering wheel heater control unit |
4L |
| N3/10 |
ME-SFI [ME] control unit |
30A |
| N3/10 |
ME-SFI [ME] control unit |
41A |
| N51/3 |
AIRMATIC control unit |
21A |
| N62 |
Parking system control unit |
25A |
| N69/1 |
Left front door control unit |
12A |
| N69/1 |
Left front door control unit |
17A |
| N99/9 |
Left front illuminated door sill molding voltage converter |
11L |
| N99/9 |
Left front illuminated door sill molding voltage converter |
16L |
| R2/10 |
Wiper park heater |
8L |
| R2/10x1 |
Wiper park position heater electrical connector |
8J |
| R4 |
Spark plugs |
30L |
| R4 |
Spark plugs |
29L |
| R4 |
Spark plugs |
33L |
| R4 |
Spark plugs |
32L |
| R4 |
Spark plugs |
31L |
| R4 |
Spark plugs |
36L |
| R4 |
Spark plugs |
35L |
| R4 |
Spark plugs |
34L |
| R4 |
Spark plugs |
40L |
| R4 |
Spark plugs |
41L |
| R4 |
Spark plugs |
42L |
| R4 |
Spark plugs |
43L |
| R4 |
Spark plugs |
44L |
| R4 |
Spark plugs |
45L |
| S12 |
Parking brake indicator switch |
1L |
| S62/43 |
Left engine hood contact switch |
7L |
| S62/43 |
Left engine hood contact switch |
25L |
| T1/1 |
Cylinder 1 ignition coil |
28K |
| T1/1 |
Cylinder 1 ignition coil |
43K |
| T1/2 |
Cylinder 2 ignition coil |
29K |
| T1/2 |
Cylinder 2 ignition coil |
44K |
| T1/3 |
Cylinder 3 ignition coil |
30K |
| T1/3 |
Cylinder 3 ignition coil |
45K |
| T1/4 |
Cylinder 4 ignition coil |
31K |
| T1/4 |
Cylinder 4 ignition coil |
40K |
| T1/5 |
Cylinder 5 ignition coil |
33K |
| T1/5 |
Cylinder 5 ignition coil |
41K |
| T1/6 |
Cylinder 6 ignition coil |
34K |
| T1/6 |
Cylinder 6 ignition coil |
42K |
| T1/7 |
Cylinder 7 ignition coil |
35K |
| T1/8 |
Cylinder 8 ignition coil |
36K |
| U1018 |
Valid for gasoline engine 276 |
38A |
| U1019 |
Valid for gasoline engine 278 |
27A |
| U1028 |
Valid for engine 157 |
36A |
| U1028 |
Valid for engine 157 |
27A |
| U12 |
Valid for left-hand drive vehicles |
1A |
| U13 |
Valid for right-hand drive vehicles |
14A |
| U135 |
Valid for Electronic Toll Collection |
18G |
| U240 |
Valid for all except ECO start/stop function |
38B |
| U252 |
Valid for ECO start/stop function |
38B |
| U52 |
Valid for Japan |
18G |
| U538 |
Valid for parking system |
23A |
| U631 |
Valid for COMAND |
18F |
| U709 |
Valid for wiper park position heater |
8F |
| U715 |
Valid for illuminated door sills |
9F |
| U715 |
Valid for illuminated door sills |
14F |
| U836 |
Valid for AIRMATIC |
19A |
| W15/2 |
Left footwell ground point |
8E |
| W15/2 |
Left footwell ground point |
21E |
| W16/5 |
Left major assembly compartment electronics ground point |
29E |
| W16/5 |
Left major assembly compartment electronics ground point |
40E |
| X11/4 |
Diagnostic connector |
13L |
| X11/4 |
Diagnostic connector |
32A |
| X11/4 |
Diagnostic connector |
44A |
| X137/1 |
VICS and Electronic Toll Collection power supply electrical connector |
19H |
| X26 |
Interior and engine wiring harness electrical connector |
30E |
| X26 |
Interior and engine wiring harness electrical connector |
42E |
| X30/30 |
Vehicle floor chassis CAN voltage distributor electrical connector |
7A |
| X30/32 |
Left vehicle floor interior CAN voltage distributor electrical connector |
3A |
| Y16/2 |
Heating system shutoff valve |
35A |
| Y16/2 |
Heating system shutoff valve |
46A |
| Z6z1 |
Circuit 31 connector sleeve |
31G |
| Z6z1 |
Circuit 31 connector sleeve |
45G |
| Z6z2 |
Circuit 31 connector sleeve |
35G |
| Z6z2 |
Circuit 31 connector sleeve |
42G |
