| A0 |
Color code key |
23L |
| A2/37 |
VICS control unit |
15L |
| A2/91 |
Bluetooth antenna |
18L |
| A2/91x1 |
Bluetooth antenna electrical connector |
18H |
| A2/94 |
ETC/DSRC antenna |
12L |
| A28/11 |
Multifunction antenna |
20L |
| A40/3 |
COMAND control unit |
12A |
| A40/3 |
COMAND control unit |
20A |
| A50/3 |
Electronic Toll Collection control unit |
9L |
| N10/2 |
Rear SAM control unit with fuse and relay module |
3L |
| N10/2f83 |
Fuse 83 |
2L |
| U12 |
Valid for left-hand drive vehicles |
5H |
| U13 |
Valid for right-hand drive vehicles |
5H |
| U135 |
Valid for Electronic Toll Collection |
1D |
| U136 |
Valid for Vehicle Information and Communication System (VICS) |
13D |
| W15/1 |
Right footwell ground point |
5L |
| W15/2 |
Left footwell ground point |
5L |
| X137/1 |
VICS and Electronic Toll Collection power supply electrical connector |
6H |
| X137/1 |
VICS and Electronic Toll Collection power supply electrical connector |
8H |
